神钢零件查询(ED190LC) - BLADE RUNNER EXCAVATOR/DOZER BTW YL02U0101 - YL03U0135 (1/02-12/06) (06-036) - PUMP ASSY, GEAR, P/N YX10V00004F1 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
720 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YX10V00004F1 | [1] | PUMP | KOB Superseded by part number: 77279971, YX10V00004F2 |
| 307. | NSS | [1] | NOT SOLD SEPARAT | CONPOPPET, INCL IN REPAR KIT |
| 308. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT, INCL IN REPAR KIT |
| 309. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT, SPRING, INCL IN REPAR KIT |
| 310. | YN10V00006S310 | [1] | SPRING | KOB |
| 311. | YT10V00003S660 | [1] | SCREW | KOB |
| 312. | YN10V00006S312 | [1] | LOCK NUT | KOBM14x1.50mm |
| 351. | NSS | [1] | NOT SOLD SEPARAT | CONCASE, INCL IN REPAR KIT |
| 353. | NSS | [1] | NOT SOLD SEPARAT | CONGEAR, DRIVE, INCL IN REPAR KIT |
| 354. | NSS | [1] | NOT SOLD SEPARAT | CONGEAR, DRIVE, INCL IN REPAR KIT |
| 355. | YN10V00006S355 | [1] | FILTER | KOB |
| 361. | NSS | [1] | NOT SOLD SEPARAT | CONCASE, INCL IN REPAR KIT |
| 433. | YN10V00006S433 | [2] | SOCKET | KOBM08 |
| 434. | YN10V00006S434 | [2] | SOCKET | KOBM08 |
| 435. | YN10V00014S435 | [4] | BOLT | KOBM10 |
| 466. | 2441U667S466 | [1] | PLUG | KOB1/4" PF |
| 467. | YN10V00006S467 | [1] | ADAPTER | KOB1/2" x 3/8" PF |
| 700. | YN10V00006S700 | [1] | RING | KOB |
| 710. | ZD12G09500 | [1] | O-RING,3.1mm Thk x 94.4mm ID, 90 Duro | KOBO-Ring -- ID 94.40 ± 0.81 x OD 100mm |
| 725. | ZD12P01100 | [1] | O-RING | KOBID 10.8mm x OD 13.2mm |
| 728. | ZD12P01800 | [1] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 732. | ZD12P01600 | [1] | O-RING | KOBID 15.80 ± 0.20 x OD 20mm |
| 850. | ZR26X01800 | [1] | RING | KOBRetaining -- ID 18 x OD 19.5 x Th 1.0mm |
| . . | YX10V00004R100 | [1] | REPAIR KIT | KOB |
| . . | YX10V00004R200 | [1] | REPAIR KIT | KOBNCL REF 308, 351,353, 354,361 Superseded by part number: YX10V00004F2 |
