纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (03-028[00]) - HYD LINES, ARM (ROTATION) 2.4M, 2.94M, 3.5M New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
568 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN43H01600P1 | [1] | TUBE | KOB2.4M Arm |
| 1. | YN43H01675P1 | [1] | TUBE,22.0 mm OD | KOB2.94M & 3.5M Arm, Shown |
| 2. | YN43H01601P1 | [1] | TUBE | KOB2.4M Arm |
| 2. | YN43H01676P1 | [1] | TUBE,22.0 mm OD | KOB2.94M & 3.5M Arm, Shown |
| 3. | YN43H01669P1 | [1] | BRACKET | KOB |
| 4. | YN43H01671P1 | [1] | BRACKET | KOB |
| 5. | ZX58N10150 | [2] | FLEXIBLE HOSE | KOBHOSE 2.4M Arm |
| 5. | ZX58N10155 | [2] | HOSE | KOB2.94M Arm, Shown |
| 5. | ZX58N10210 | [2] | HYDRAULIC HOSE | KOB3.5M Arm |
| 7. | ZC26X22011 | [6] | CLAMP | KOBSingle Line -- 38x29x65mm Long |
| 8. | ZM73C10045 | [6] | BOLT,M10x45mm - Course Thread | KOBM10x1.50x45mm (Incls. Washer) |
| 9. | ZS18C16040 | [4] | SCREW,Hex, M16 x 40mm | KOBM16x2.0x40mm |
| 10. | ZW16H16000 | [4] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| 11. | 2444T2657D1 | [2] | HYD CONNECTOR | KOB |
| 12. | 2420T4405 | [2] | PLUG | KOB3/4"-16UNF x 22mm Long |
