纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (07-004[00]) - VALVE, CONTROL (N&B) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
114 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 101. | NSS | [1] | NOT SERVICED SEPARATELY | CONCASE |
| 161. | ZD12G05500 | [1] | O-RING,3.1mm Thk x 54.4mm ID, 90 Duro | KOBO -- ID 54.40 ± 0.49 x OD 60mm |
| 162. | ZD12P00900 | [1] | O-RING | KOBID 08.80 ± 0.17 x OD 12mm |
| 201. | YN30V00104S201 | [1] | COVER | SM |
| 301. | YN30V00104S301 | [1] | SPOOL | SMSPOOL |
| 321. | YN30V00104S321 | [1] | SPRING | SM |
| 601. | YN35V00050F1 | [1] | SOLENOID VALVE,Cartridge W/Coil | KOBVALVE ASSY,SOLENOID |
| 701. | ZS23C10025 | [2] | SCREW,Hex Socket Head, M10 x 25mm | KOBM10x1.50x25mm Superseded by part number: ZS28C10025 |
| 702. | YX35V00002S171 | [2] | SCREW,Hex Socket Head, M5 x 12mm | KOBM05x0.8x12mm Superseded by part number: ZS23C05012 |
| 703. | ZS23C12105 | [3] | SCREW,Hex Socket Head, M12 x 105mm | KOBM12x1.75x105mm |
| 704. | ZS23C12080 | [1] | SCREW,Hex Socket Head, M12 x 80mm | KOBM12x1.75x80mm |
