凯斯零件查询(LB334S) - BALER (9/12-) (60.220.071) - PICK-UP, REEL - F085136 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
658 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84607784
|
[1] |
CAM
|
ZED
|
| 2. |
47503280
|
[1] |
ROTOR
|
ZED
, Serial Range: -C094 Superseded by part number: 47638428
|
| 2. |
47638428
|
[1] |
SHAFT
|
ZED
, Start Serial: D095
|
| 2. |
84572494
|
[1] |
SHAFT
|
ZED
, Serial Range: -C094 Superseded by part number: 47535634
|
| 2. |
47535634
|
[1] |
SHAFT
|
ZED
, Start Serial: D095
|
| 3. |
47503275
|
[4] |
SHAFT
|
ZED
|
| 3. |
47499953
|
[4] |
SHAFT
|
ZED
|
| 4. |
84058012
|
[4] |
BUSHING,15.88mm ID x 30mm OD x 16mm L
|
ZED
|
| 5. |
54770
|
[12] |
BALL BEARING,27.33 mm ID x 47.092 mm OD x 25.4 mm
|
NH
Superseded by part number: 84330047
|
| 6. |
54695
|
[12] |
BEARING HOUSING
|
NH
|
| 7. |
84056924
|
[4] |
CAM FOLLOWER,Tine Shaft
|
ZED
|
| 8. |
446691
|
[4] |
WASHER,16mm ID x 32mm OD x 5mm Thk
|
ZED
|
| 9. |
86511416
|
[4] |
JAM NUT,Jam, 5/8"-18, G2
|
ZED
|
| 10. |
84301451
|
[56] |
REEL TINE
|
ZED
4.75MM, Serial Range: -C098
|
| 10. |
84582461
|
[56] |
TINE
|
ZED
5.5MM, Start Serial: D099
|
| 11. |
120041
|
[1] |
CARRIAGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 12. |
100037
|
[1] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 13. |
86627654
|
[56] |
SPACER
|
NH
, Serial Range: -C098 Superseded by part number: 84427925
|
| 13. |
84382002
|
[56] |
SUPPORT
|
ZED
, Start Serial: D099
|
| 14. |
136521
|
[1] |
COTTER PIN,5.7mm OD x 44.45mm L
|
NH
|
| 15. |
87643386
|
[56] |
BRACKET
|
NH
|
| 16. |
535866
|
[1] |
SCREW
|
GI
|
| 17. |
86629542
|
[1] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 18. |
9706704
|
[3] |
BOLT,Hex, M10 x 1.5 x 41.58mm, Cl 8.8
|
NH
|
| 19. |
140045
|
[3] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 20. |
100016
|
[3] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 21. |
442245
|
[12] |
WASHER,35mm ID x 51.5mm OD x 0.8mm Thk
|
ZED
|
| 22. |
84078001
|
[8] |
COLLAR CLAMP
|
ZED
|
| 23. |
86624176
|
[1] |
WASHER,11mm ID x 20mm OD x 2mm Thk
|
FOR
Superseded by part number: 14496621
|
