凯斯零件查询(LB334S) - BALER (9/12-) (60.220.090) - FEED ROLLER - C084 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
622 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84216309
|
[1] |
FEED ROLLER
|
ZED
|
| 1. |
84361352
|
[1] |
FEED ROLLER
|
ZED
, Serial Range: -C144
|
| 1. |
47943549
|
[1] |
FEED ROLLER
|
ZED
, Start Serial: D145
|
| 1. |
47583494
|
[1] |
FEED ROLLER
|
ZED
|
| 2. |
84488422
|
[1] |
SPROCKET
|
ZED
|
| 3. |
36403
|
[4] |
BEARING HOUSING
|
GI
Superseded by part number: 578189
|
| 4. |
9837842
|
[2] |
BEARING,35mm ID x 72mm OD x 19mm W
|
ZED
|
| 5. |
170012
|
[1] |
KEY,8mm W x 50mm OAL
|
ZED
|
| 6. |
86633356
|
[3] |
CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8
|
ZED
|
| 7. |
140045
|
[6] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 8. |
100016
|
[6] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 9. |
84429871
|
[4] |
WASHER
|
PLO
|
| 10. |
370004
|
[1] |
SNAP RING,M35 x 1.5mm Thk, External
|
NH
Superseded by part number: 11068376
|
