纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (08-017[02]) - INJECTION PUMP - CONTROL New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
938 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4896616 | [1] | DRIVEN GEAR | TOR |
| 2. | 2852885 | [1] | GASKET,1.2mm Thk | TOR |
| 3. | 2852347 | [3] | STUD | TOR Superseded by part number: 504065125 |
| 4. | 4899003 | [3] | FLANGE NUT,M8 x 1.25 | TORM08x1.25mm Superseded by part number: 17044735 |
| 5. | 2852350 | [1] | RIGID TUBE | TOR Superseded by part number: 504038511 |
| 6. | 4893518 | [1] | TUBE,M8 x 1 x 29.5 L | TORM08x1.0mm |
| 7. | 4896770 | [1] | TUBE NUT,M10 x 1 | TORM10x1.0mm |
| 8. | 2852057 | [1] | SEALING WASHER,M8 x 12 x 1 Thk | TORSEAL WASHER |
