纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (08-019[00]) - FUEL FILTER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
632 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87350323 | [1] | FUEL FILTER | SM- ASSY (FILTRAUTO) |
| 2. | 2853320 | [1] | SUPPORT | TOR Superseded by part number: 504002420 |
| 3. | 4899068 | [2] | BOLT,Flng, M8 x 1.25 x 16mm | BASM08x1.25x16mm |
| 4. | 4899093 | [2] | BOLT,Hex Flange, M10 x 30.00mm, Cl 10.9, PHC | BASM10x1.50x30mm |
| 5. | 4895166 | [2] | FLANGE NUT,M10, 1.50mm Pitch, Cl 10 | BASM10x1.50mm |
| 6. | 87646724 | [2] | FUEL FILTER | KOB Superseded by part number: 84565884 |
