纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (08-020[00]) - FUEL PUMP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
409 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2830266 | [1] | FUEL PUMP | TORASSY Superseded by part number: 4890964, 4894721 |
| 2. | 2830156 | [1] | O-RING,70 Duro, M2.62 Thk | TOR |
| 3. | 4899031 | [2] | BOLT,Flng, M8 x 1.25 x 25mm | TORM08x1.25x25mm Superseded by part number: 4899079 |
| 4. | 4890964 | [2] | FITTING,M12 x 1.5 | TORQuick Disconnect, M12x1.50x26mm |
| 5. | 4894721 | [2] | SEALING WASHER,12.2mm ID x 17mm OD x 1.5mm Thk | TOR |
