神钢零件查询(ED190LC) - BLADE RUNNER EXCAVATOR/DOZER BTW YL02U0101 - YL03U0135 (1/02-12/06) (07-014) - ATTACHING PARTS Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
387 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 01385B. | VAMH037790 | [1] | PLUG,CYLINDER BLOCK, SCREW,16, 0001-1- | |
| 01385C. | VAMH037725 | [2] | PLUG CYLINDER BLOCK, TAPER,1/8, 0001-1- | |
| 01395B. | VAMS666139 | [1] | CAP | KOBCAP, CYLINDER BLOCK, SEALING,30, 0001-1- |
| 01395D. | VAMH037774 | [1] | CAP | KOBCAP.CYLIDER BLOCK, SEALING,D=17.2, 0001-1- |
| 01399D. | VAMF660066 | [1] | GASKET | KOBGASKET, CYLINDER BLOCK, 16, 0001-1- Superseded by part number: VAF420216000 |
| 02200. | VAME019084 | [1] | ENGINE HANGER, 0001-1- | |
| 02200C. | VAME080606 | [1] | ENGINE HANGER, 0001-1- | |
| 02299B. | VAMF140223 | [2] | BOLT | KOBBOLT ENG HANGER, FLANGE,8X16, 0001-1- |
| 02299C. | VAMH000713 | [2] | BOLT | KOBBOLT.ENG HANGER, FLANGE,10X20, 0001-1- |
| 04203B. | VAMF660063 | [2] | GASKET | KOBGASKET, ENG OIL PRESSURE GAUGE, 0001-1- Superseded by part number: VAF420210000 |
| 04208. | VAMH037279 | [1] | BOLT | KOBEYEBOLT.ENG OIL PRESSURE GAUGE, 10X20, 0001-1- |
| 04226. | VAMC840219 | [1] | SWITCH | KOBSWITCH, ENG OIL PRESSURE, 0001-1- Superseded by part number: H411892 |
| 04296. | VAMS666220 | [1] | PLUG | KOBPLUG, ENG OIL PRESSURE GAUGE, TAPER,1/8, 0001-1- |
