凯斯零件查询(LB334S) - BALER (9/12-) (70.200.030) - TENSION RAILS Case Agriculture

广数供应链运营团队, 15 02月, 2025，浏览： 880 次

Pos.	Part No	Qty	Parts name	Comments
1.	84260542	[1]	DOOR	ZED
1.	84260555	[1]	DOOR	ZED
1.	47949348	[1]	DOOR	ZED
2.	84260563	[1]	DOOR	ZED
2.	47949382	[1]	DOOR	ZED
3.	84260566	[1]	DOOR	ZED
3.	47949386	[1]	DOOR	ZED
4.	84800563	[4]	SHAFT	ZED , Serial Range: -C144
4.	47923025	[2]	SHAFT	ZED , Start Serial: D145
5.	87670112	[2]	SHAFT	ZED , Serial Range: -C144
5.	47776338	[2]	SHAFT	ZED , Start Serial: D145
6.	84528308	[2]	SHAFT,20mm OD x 92mm L	ZED , Serial Range: -C144
6.	47776340	[2]	SHAFT	ZED , Start Serial: D145
7.	9838030	[4]	ROLLER,20.25mm ID x 75mm OD x 20mm L	ZED
8.	84418384	[4]	SHAFT	ZED
9.	84260539	[1]	ARTICULATED SHAFT,22mm OD x 1048mm L	ZED
9.	84260553	[1]	ARTICULATED SHAFT,22mm OD x 1432mm L	ZED
10.	84260544	[2]	ARTICULATED SHAFT	ZED
11.	87654282	[4]	LEVER	ZED
11.	87697863	[4]	LEVER	ZED
12.	9838429	[4]	SPHERICAL BEARING,25mm ID x 42mm OD x 20mm W	ZED
13.	916111	[8]	WASHER	ZED
14.	300632	[8]	SNAP RING,M38, External	ZED , Serial Range: -C144 Superseded by part number: 11068676
14.	84603132	[8]	CIRCLIP	ZED , Start Serial: D145
15.	401502	[1]	ANTI-SKID STRIP	ZED L=5.44M
16.	412687	[2]	COTTER PIN,6.3mm OD x 32mm OAL	MOD
17.	384927	[8]	WASHER,20mm ID x 32mm OD x 4mm Thk	ZED
18.	84000320	[2]	WASHER	ZED
19.	370024	[4]	CIRCLIP,M20, Ext	NH , Serial Range: -C144
19.	86625140	[4]	SNAP RING,M20, Ext	IMO , Start Serial: D145
20.	378248	[4]	WASHER,25mm ID x 50mm OD x 4mm Thk	ZED
21.	370002	[4]	CIRCLIP,M25, External	NH
22.	84800564	[8]	WASHER,38.5mm ID x 50mm OD x 2mm Thk	ZED
23.	300872	[2]	LOCK PIN,8mm OD x 36mm L, Slotted	GI
