纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (02-006[03]) - IDLER ADJUST ASSEMBLY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
304 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN54D00014F2 | [1] | IDLER WHEEL | SMAdjuster Assembly Superseded by part number: YN54D00015F2 |
| 1. | YN70V00006P1 | [1] | GREASE | KOBCylinder |
| 2. | YN54D01051P1 | [1] | YOKE | SMBracket |
| 3. | YN54D01038P1 | [1] | NUT | KOBM52x3.0mm |
| 4. | ZP26D08080 | [1] | PIN | KOBRoll -- OD 08 x 80mm Long |
| 5. | YN54D01062P1 | [1] | SPRING | SMSpring Superseded by part number: YN54D01063P1 |
| 6. | YN01V01099P1 | [1] | PISTON | KOB |
| 7. | YN54D01042P1 | [1] | COLLAR | KOB |
| 8. | ZD12G08000 | [1] | O-RING,79.40mm ID x 85.60mm OD x 3.10mm | KOBID 79.40 ± 0.69 x OD 85mm |
| 9. | 2418U130D35 | [1] | PACKING | KOBOil Seal |
| 10. | LQ54D01023P1 | [2] | PIN | SM |
| 11. | YN54D01029P1 | [1] | COVER | KOB |
