纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (02-010[00]) - FRAME, LOWER H & W FULL TRACK GUARD New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
699 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2422T556 | [1] | PLATE | KOB |
| 2. | 2418T12274 | [1] | PACKING | KOB |
| 3. | 2420P1580D1 | [28] | SCREW,M18 x 1.5 x 40mm | KOB |
| 4. | ZM73C12025 | [8] | BOLT,M12x25mm - Course Thread | KOB |
| 5. | ZS18C10014 | [2] | SCREW,Hex, M10 x 14mm | KOB |
| 6. | ZW26X10000 | [2] | LOCK WASHER | KOB |
| 7. | LQ01FU1015P1 | [4] | BOLT,M24 x 3 x 50mm | KOB |
| 8. | LQ01FU1016P1 | [2] | BOLT,M24 x 3 x 110mm | KOB |
| 9. | ZN23C24027 | [2] | SLOTTED NUT | KOB |
| 10. | ZP15D05045 | [2] | PIN | KOB Superseded by part number: ZP15D05080 |
| 11. | YN01F01096P1 | [2] | STONEGUARD | KOB |
| 12. | YN01FU1033P1 | [2] | COVER | KOB |
| 13. | YN01FU1034P1 | [2] | COVER ASSY | KOB |
| 14. | NSS | [4] | NOT SERVICED SEPARATELY | CON |
