现代零件查询R320LC-7A BOOM MOUNTINGEPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
610 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
61N9-00011
|
[1] |
PIN ASSY
|
|
| 1. |
61N9-00012
|
[1] |
PIN ASSY
|
|
| 1. |
61N9-00012BG
|
[1] |
PIN ASSY
|
|
| 1. |
61N9-00012-AS
|
[1] |
PIN ASSY
|
|
| 2. |
61N8-01770
|
[1] |
PIN ASSY
|
|
| 2. |
61N8-01771
|
[1] |
PIN ASSY
|
|
| 2. |
61N8-01771-AS
|
[1] |
PIN ASSY
|
|
| 3. |
61N9-00060
|
[1] |
PIN
|
|
| 3. |
61N9-00061
|
[1] |
PIN ASSY
|
|
| 3. |
61N9-00061-AS
|
[4] |
PIN ASSY
|
|
| 4. |
61N8-01860
|
[4] |
PIN ASSY
|
|
| 4. |
61N8-01861
|
[4] |
PIN ASSY
|
|
| 4. |
61N8-01861BG
|
[4] |
PIN ASSY
|
|
| 4. |
61N8-01861BG
|
[2] |
PIN ASSY
|
|
| 4. |
61N8-01861-AS
|
[4] |
PIN ASSY
|
|
| 5. |
61N9-00031
|
[1] |
PIN ASSY
|
|
| 5. |
61N9-00031-AS
|
[1] |
PIN ASSY
|
|
| 6. |
61NA-00030
|
[1] |
PLATE-LOCK
|
|
| 6. |
61NA-00030BG
|
[1] |
PLATE-LOCK
|
|
| 8. |
61N8-10810
|
[1] |
PLATE-LOCK
|
|
| 9. |
61N8-00170
|
[1] |
SPACER-PIN
|
|
| 9. |
61Q8-00150
|
[1] |
SPACER-PIN
|
|
| 10. |
61N8-00180
|
[4] |
SPACER-PIN
|
|
| 10. |
61Q8-00160
|
[4] |
SPACER-PIN
|
|
| 11. |
S017-20030D
|
[5] |
BOLT-HEX
|
|
| 12. |
S017-16045D
|
[4] |
BOLT-HEX
|
|
| 13. |
61N8-00320
|
[5] |
WASHER-HARDENED
|
|
| 14. |
S411-160006
|
[4] |
WASHER-SPRING
|
|
| 16. |
S391-100170
|
[2] |
SHIM-ROUND(1.0T)
|
|
| 17. |
S391-090165
|
[1] |
SHIM-ROUND(1.0T)
|
|
| 18. |
S391-100165
|
[1] |
SHIM-ROUND(1.0T)
|
|
| 20. |
61N8-19030
|
[2] |
STOPPER-PIN
|
|
| 21. |
S017-161806
|
[2] |
BOLT-HEX
|
|
| 22. |
S205-16100B
|
[4] |
NUT-HEX
|
|
| 23. |
S390-100200A
|
[1] |
SHIM-ROUND(0.5T)
|
|
| 24. |
S390-110200A
|
[1] |
SHIM-ROUND(0.5T)
|
|
| 25. |
61N8-01890BG
|
[2] |
PIN ASSY
|
|
