| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
61N9-20900
|
[1] |
ARM ASSY(3.2M)-H/DUTY
|
|
| . |
61N9-20901
|
[1] |
ARM ASSY(3.2M)-H/DUTY
|
|
| 1. |
61N9-29010
|
[1] |
ARM WA(3.2M)-H/DUTY
|
|
| N1. |
61N9-29011
|
[1] |
ARM WA(3.2M)-H/DUTY
|
|
| N1. |
61N9-29012
|
[1] |
ARM WA(3.2M)-H/DUTY
|
|
| 2. |
61EN-17120
|
[2] |
BUSHING
|
|
| 3. |
61EN-13380
|
[2] |
BUSHING
|
|
| 4. |
61EN-12310
|
[2] |
BUSHING-BRONZE
|
|
| 5. |
S700-100208
|
[4] |
DUST SEAL-DKIY TYPE
|
|
| 6. |
S700-090206
|
[2] |
DUST SEAL-DKIY TYPE
|
|
| 7. |
S651-810002
|
[2] |
NIPPLE-GREASE
|
|
