纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-039[00]) - CONTROL LINES, MULTI New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
438 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN30V00115F1 | [1] | CONTROL VALVE | KOBSee Fig. 07-009(00) |
| 2. | YN64H01349P1 | [1] | BRACKET | KOB |
| 3. | HX33L06105CG | [1] | HYDRAULIC HOSE | KOB1050mm Long (41-21/64 in) |
| 4. | HX33L06110CG | [1] | HYDRAULIC HOSE | KOB1100mm Long (43-19/64 in) |
| 5. | HX33L06110CH | [1] | HYDRAULIC HOSE | KOB1100mm Long (43-19/64 in) |
| 6. | HX33L06110CB | [1] | HYDRAULIC HOSE | KOB1100mm Long (43-19/64 in) |
| 7. | ZH22X06000 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01400) |
| 8. | 2444Z2337 | [4] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| 9. | 2444Z2516 | [2] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| 10. | 2444Z3822 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) Superseded by part number: YY42H01633P1 |
| 11. | ZH32X06000 | [1] | 90 ELBOW,Male, 30° Fl, PF 3/8" x PF 3/8", O-Ring | KOBElbow, 90° -- (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 |
| 12. | 2444Z2338 | [1] | ELBOW | KOB90° -- (1/4" PFx3/8" PF), (Incls. O-Ring ZD12P01100) |
| 13. | 2444Z3155 | [2] | 90 ELBOW,PF 3/8" Fem x PF 3/8" Male | KOB90° -- (PF 3/8) (Incls. O-Ring ZD12P01400) Alternate O-Ring 237-6006 Superseded by part number: YT42H01128P1 |
| 14. | ZE72X04000 | [4] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 15. | ZC47X14011 | [2] | CLIP | KOBClamp, Double -- Ø14x56mm Long |
| 16. | ZY26X06015 | [1] | SPACER | KOB |
| 17. | ZM73C08016 | [4] | BOLT,M8x16mm - Course Thread | KOBM08x1.25x16mm (Incls. Washer) |
| 18. | ZM73C10025 | [4] | BOLT,M10x25mm - Course Thread | KOBM10x1.50x25mm (Incls. Washer) |
| 19. | ZM73C10040 | [1] | BOLT,M10x40mm - Course Thread | KOBM10x1.50x40mm (Incls. Washer) |
| 20. | YN64H01351P1 | [1] | GROMMET | KOB |
| 21. | YN21C03574P1 | [1] | COVER | KOB |
