神钢零件查询(ED190LC) - BLADE RUNNER EXCAVATOR/DOZER BTW YL02U0101 - YL03U0135 (1/02-12/06) (01-057[01]) - PANEL ASSY, INSTRUMENT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
666 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YM17MU0001F1 | [1] | INSTRUMENT PANEL ASSY (STD & BREAKER) | |
| . . | YM17MU0001F2 | [1] | INSTRUMENT PANEL ASSY (NIBBLER & BREAKER) | |
| 1. | YN17M01051F1 | [1] | COVER | KOB |
| 1-1. | YN17M01048P1 | [1] | COVER | KOB |
| 1-3. | YN17M01064P1 | [1] | PANEL | KOB |
| 2. | YM17MU1003F1 | [1] | COVER ASSY | |
| 2-1. | YM17MU1001P1 | [1] | COVER | |
| 2-2. | YN50S00002F1 | [1] | IGNITION SWITCH | KOB Superseded by part number: YN50S00026F1 |
| 2-2A. | 2420Z1030D2 | [1] | KIT | KOBKEY, MANUFACTURER P/N YN50S00002S001 Superseded by part number: PM50S01001P1 |
| 2-3. | YN07M01070P1 | [1] | LABEL | |
| 3. | YN17M01047P1 | [1] | COVER | KOB |
| 4. | YN59E00004F1 | [1] | GAUGE | KOB Superseded by part number: YN59E00017F1, YN17M01139P1 |
| 4-1. | LC59S00001F2 | [1] | GAUGE | KOB Superseded by part number: YN59E00017F1, YN17M01139P1 |
| 4-2. | YN17M01061P3 | [1] | U-BRACKET | KOB Superseded by part number: YN17M01108P1 |
| 4-3. | YN17M01066F1 | [1] | COVER | KOB |
| 5. | YN02C01877D2 | [4] | SCREW | KOBM03x10mm Self-Taper |
| 6. | YN17M01050P1 | [1] | COVER | KOB |
| 7. | YN54S00006P1 | [2] | SPEAKER | KOB Superseded by part number: YN54S00050P2 |
| 8. | LB54S00001P1 | [1] | RADIO | KOB Superseded by part number: YN54S00074P1 |
| 9. | 2420R1089D1 | [4] | BOLT,M5 x 10mm | KOBM05x0.8x10mm (Incls. Washer & Lockwasher) |
| 10. | ZS32T40012 | [8] | SCREW | KOBM04x12mm Self-Taper |
| 11. | ZW16K04000 | [8] | WASHER | KOBID 04 x OD 08 x Th 0.8mm |
| 12. | ZM46C06020 | [8] | BOLT | KOBM06x1.0x20mm (Incls. Washer & Lockwasher) |
| 13. | YX17M01003P1 | [2] | BRACKET | KOB |
| 14. | ZM46C06016 | [7] | SCREW | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| 15. | YN17M01032P1 | [6] | CAP | KOB |
| 16. | YN02C01385F1 | [1] | TRAY | KOB |
| 17. | 2421R180F1 | [1] | CIGARETTE LIGHTER | KOB Superseded by part number: YN81S00003P1 |
| 18. | YN20M01220P1 | [2] | VENT | KOB |
| 19. | YN20M01297F1 | [1] | DUCT | KOB |
| 19-1. | YN20M01219P1 | [1] | DUCT | KOBDUCT ASSY Superseded by part number: YN20M01297F1 |
| 19-2. | YN20M01297S002 | [1] | SEAL | KOBSEAL |
| 19-3. | YN20M01297S003 | [1] | SEAL | KOBSEAL |
| 20. | YN58S00006P1 | [1] | METER | KOB |
| 21. | ZM61C08020 | [5] | BOLT | KOBM08x1.25x12mm (Incls. Washer & Lockwasher) |
| 22. | ZM66C06012 | [3] | BOLT | KOBM06x1.0x12mm (Incls. Washer & Lockwasher) |
| 23. | YN17M01072P1 | [1] | CABLE | KOB2000mm Long (78-3/4 in) Superseded by part number: 72203961 |
| 24. | YN81S00001P1 | [1] | SOCKET | KOB |
| 25. | YN17M01055D1 | [3] | CAP | KOB |
| 26. | YN17M01055D2 | [4] | CAP | KOB |
| 27. | YN17M01068P1 | [1] | SCREW | KOB |
| 28. | YN17M01060P1 | [1] | CAP | KOB |
| 29. | 2479U1190F13 | [1] | SWITCH | KOB |
| 30. | 2420T4505 | [4] | WASHER,7mm ID x 16mm OD x 1mm Thk | KOBID 07 x OD 16 x Th 1.0mm |
| 31. | 2479U1224F4 | [1] | SWITCH | KOB |
| 32. | 2479U1190F5 | [1] | SWITCH | KOB |
| 33. | 2479U1190F9 | [1] | SWITCH | KOB |
| 34. | 2420Z1330 | [1] | GROMMET | KOB |
| 35. | YN50E00003F1 | [1] | SWITCH | KOB |
| 36. | YN02C01877D1 | [2] | SCREW | KOBM03x16mm Self-Taper |
| 37. | 2479U1190F31 | [1] | SWITCH | KOBAutomatic Warm-Up |
| 38. | 2479U1190F32 | [1] | SWITCH | KOB |
| 40. | ZM46C05012 | [2] | BOLT | KOBM05x0.8x12mm (Incls. Washer & Lockwasher) |
| 41. | 2479U1190F15 | [1] | SWITCH | KOB |
| 42. | YN50EU0001P1 | [1] | SWITCH ASSY (SW-2) (BUZZER STOP, WORK MODEL) | |
| 43. | 2480U376F1 | [1] | POTENTIOMETER | KOB |
| 44. | YM02CU1001P1 | [1] | KNOB | KOB |
| 45. | YM20TU1003P1 | [1] | LABEL | |
| 46. | YM03MU1012P1 | [1] | GRIP | KOB |
| 48. | YN13EU1009P1 | [2] | WIRE HARNESS | KOB |
