凯斯零件查询(LB334S) - BALER (9/12-) (88.070.001[04]) - DIA KIT: ROLLER BALE CHUTE - C136 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
536 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47599068
|
[1] |
DIA KIT, HARVESTER
|
ZED
Incl 2 - 15
|
| 2. |
47447340
|
[1] |
WIRE HARNESS
|
ZED
|
| 3. |
84391774
|
[1] |
SENSOR
|
ZED
|
| 4. |
87010656
|
[2] |
CLAMP,17.5mm, Coat, 10.3mm Bolt Hole, P Type
|
GI
|
| 5. |
86566990
|
[11] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
|
| 6. |
84007558
|
[9] |
RIVET,Pop, 4.8mm OD x 19mm L
|
ZED
|
| 7. |
9507807
|
[7] |
CLAMP,8.3mm ID, 6.7mm Bolt Hole, P Type
|
ZED
|
| 9. |
338413
|
[1] |
BOLT,Hex, M6 x 60mm, Cl 8.8
|
NH
|
| 10. |
84814948
|
[1] |
SUPPORT
|
ZED
|
| 11. |
430356
|
[1] |
CLAMP
|
ZED
|
| 12. |
322357
|
[1] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 13. |
412152
|
[1] |
NUT,M6 x 1, Cl 8.8
|
ZED
|
| 14. |
84818443
|
[2] |
CLAMP,16.3mm ID, 6.7mm Bolt Hole, P Type
|
ZED
|
| 15. |
9824326
|
[9] |
WASHER,5.3mm ID x 10mm OD x 1mm Thk
|
NH
|
