纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-058[00]) - PLATE INSTALLATION, FLOOR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
989 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| A1. | XLB03M01007P1 | [1] | PLATE | SMFLOOR |
| . . | LB03M01015P1 | [1] | DECAL | SMNot Shown (STD) |
| . . | YN03MU1011P1 | [1] | BLOCK | KOBNot Shown (Single Pedal Travel) |
| B1. | YN03M02125P1 | [2] | INSULATOR BLOCK | SMRUBBER |
| B2. | ZM22C10035 | [16] | BOLT | KOBM10x1.50x35mm (Incls. Washer & Lockwasher) |
| B3. | ZW16H16000 | [4] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| B4. | ZN18C16013 | [4] | NUT | KOBM16x2.0mm |
| B5. | YN03M02126P1 | [2] | INSULATOR BLOCK | SMRUBBER |
| B6. | YN03M02128P1 | [2] | GASKET | SM |
| B8. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
