凯斯零件查询(LB334S) - BALER (9/12-) (88.070.012[01]) - DIA KIT: FIXED KNIFE & HAY-DOGS - STONE KIT - D099 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
304 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47879690
|
[1] |
DIA KIT, HARVESTER
|
ATT
Incl 2 - 17
|
| 2. |
84400465
|
[1] |
KNIFE
|
ZED
|
| 3. |
47429062
|
[4] |
GUIDE
|
ZED
|
| 4. |
47497510
|
[1] |
GUIDE
|
ZED
|
| 5. |
47885362
|
[1] |
GUIDE
|
ZED
|
| 6. |
47885359
|
[1] |
GUIDE
|
ZED
|
| 7. |
47497512
|
[1] |
GUIDE
|
ZED
|
| 8. |
47885356
|
[2] |
GUIDE
|
ZED
|
| 9. |
47885353
|
[2] |
GUIDE
|
ZED
|
| 10. |
380420
|
[9] |
BOLT
|
NH
|
| 11. |
87376144
|
[9] |
WASHER,13mm ID x 28mm OD x 5mm Thk
|
FLX
|
| 12. |
9706685
|
[29] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 13. |
9824642
|
[4] |
BOLT,M12 x 1.75 x 42.68mm, Cl 10.9
|
BHB
Superseded by part number: 626-12035
|
| 14. |
47510146
|
[4] |
PLOW BOLT,M12 x 100, Cl 8.8
|
ZED
|
| 15. |
140046
|
[24] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 16. |
328754
|
[12] |
CARRIAGE BOLT,M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 17. |
47480247
|
[4] |
CARRIAGE BOLT,Short Sq Nk, M12 x 1.75 x 100mm, Cl 8.8
|
ZED
|
