纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-064[14]) - CAB - WINDOW ASSY, FR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
424 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LQ50C00002F2 | [1] | WINDOW | KOBAssy (See Fig 01-064[15]) Superseded by part number: LQ52C00010S002, LQ50C00003F1, LQ52C00010S001 |
| 3. | LQ50C00001S003 | [1] | BRACKET | KOB |
| 4. | LQ50C00001S004 | [1] | BRACKET | KOB |
| 5. | LQ50C00001S005 | [1] | STRIKER | KOBSTRIKER |
| 6. | NSS | [1] | NOT SERVICED SEPARATELY | CON- ASSY (Order Components) |
| 6A. | LQ02C01316S001 | [1] | BRACKET | KOB |
| 6B. | LQ02C01316S002 | [1] | HOOK | KOB |
| 6C. | LQ02C01316S003 | [1] | STOP | KOB |
| 6D. | LQ02C01316S004 | [2] | NUT | KOB |
| 7. | LQ50C00001S007 | [1] | CABLE TERMINAL | KOB |
| 8. | LQ50C00001S008 | [1] | SEAL, GLASS | KOBSEAL,WINDOW |
| 9. | LQ50C00001S009 | [1] | RUBBER BLOCK | KOB |
| 10. | LQ50C00001S010 | [1] | STOP PLUG | KOB |
| 11. | LQ50C00001S011 | [2] | RUBBER BLOCK | KOB |
| 12. | LQ50C00001S012 | [1] | SWITCH | KOB |
| 13. | LQ50C00001S013 | [7] | BOLT | KOB |
| 14. | LQ50C00001S014 | [2] | BOLT | KOB |
| 15. | LQ02C00031S031 | [6] | BOLT | KOB |
| 16. | LQ50C00001S016 | [2] | SCREW | KOB |
| 17. | LQ50C00001S017 | [1] | NUT | KOB |
| 18. | LQ50C00001S018 | [1] | INLET MANIFOLD | KOB |
| 19. | LQ50C00001S019 | [1] | INLET MANIFOLD | KOB |
| 20. | LQ50C00001S020 | [2] | BOLT | KOB |
| 21. | LQ50C00001S021 | [1] | SHIM | KOB |
