神钢零件查询(ED190LC-6E) - BLADE RUNNER EXCAVATOR/DOZER BTW YL03U0136 - YL03U0292 (1/05-12/06) (07-002) - VALVE, RELIEF Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
545 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2436R1119F7 | [1] | HYDRAULIC VALVE | KOBVALVE ASSY, RELIEF |
| 1. | NSS | [1] | NOT SOLD SEPARAT | CONCAP |
| 2. | NSS | [1] | NOT SOLD SEPARAT | CONPLUG |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONSLEEVE |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONPOPPET, MAIN |
| 5. | NSS | [1] | NOT SOLD SEPARAT | CONSEAT, PILOT |
| 6. | NSS | [1] | NOT SOLD SEPARAT | CONPOPPET, PILOT |
| 7. | NSS | [1] | NOT SOLD SEPARAT | CONADJUSTER |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CONSPRING, PILOT |
| 9. | NSS | [1] | NOT SOLD SEPARAT | CONSPRING, PILOT |
| 10. | 2436R1119S10 | [1] | O-RING | KOBO-RING |
| 11. | 2436R1119S11 | [1] | BACK-UP RING | KOBRING, BACK-UP |
| 12. | 2436U388S5 | [1] | O-RING | KOBO-RING |
| 13. | 2436U388S25 | [1] | O-RING | KOBO-RING |
| 14. | NSS | [1] | NOT SOLD SEPARAT | CONNAME PLATE |
| 15. | ZD12P01000 | [1] | O-RING | KOBID 09.80 ± 0.17 x OD 13mm |
| 16. | NSS | [1] | NOT SOLD SEPARAT | CONWASHER |
| 17. | NSS | [1] | NOT SOLD SEPARAT | CONNUT |
