纽荷兰零件查询(EC130) - CRAWLER EXCAVATOR (4/99-) (06.150[001]) - IDLER ROLLER (S/N 11701-UP) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
649 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 73177013 | [1] | ROLLER | NHIDLER ROLLER Superseded by part number: 2245899 |
| 2. | 73177014 | [1] | SHAFT | NHAXLE |
| 3. | 73171598 | [1] | PLUG | NHSREW PLUG Superseded by part number: 152206076 |
| 4. | 73172110 | [2] | BUSHING | BER Superseded by part number: 71401162 |
| 5. | 73172112 | [2] | RING | NHSEALING RING Superseded by part number: 71401209 |
| 7. | 73177015 | [2] | SUPPORT | NHLID |
| 8. | 73172114 | [2] | O-RING | BER Superseded by part number: 70923580 |
| 9. | 73177016 | [2] | LOCK PIN | NHLOCKING PIN Superseded by part number: 71401207 |
| 10. | 73171604 | [1] | O-RING | BERROUND SEALING RING Superseded by part number: 151201107 |
| 11. | 73172113 | [2] | SEAL | BERDUO-CONE SEAL Superseded by part number: 71401161 |
