凯斯零件查询(LB424R) - BALER (9/12-) (05.102.011) - WHEEL BLOCKS - D099 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
452 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
47580299
|
[1] |
PROFILE
|
ZED
|
| 2. |
120044
|
[3] |
CARRIAGE BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 3. |
140046
|
[3] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 4. |
9706685
|
[3] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 5. |
47579697
|
[2] |
BRACKET
|
ZED
|
| 6. |
120104
|
[8] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 7. |
322358
|
[8] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 8. |
9706690
|
[8] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 9. |
47579696
|
[2] |
WHEEL CHOCK
|
ZED
|
