纽荷兰零件查询(EC130) - CRAWLER EXCAVATOR (4/99-) (16.031[001]) - SLEWING GEAR MOUNTING PARTS (S/N 11701-UP) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
914 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NS | [1] | NOT SERVICED | BASSLEWING GEAR INSTALL.MATERIAL SEE FIGURE 16.030/001 |
| 2. | 73172369 | [1] | SENSOR | BERSPEED SENSOR Superseded by part number: 3005851 |
| 4. | 73189565 | [1] | FLEXIBLE HOSE | BERHOSE, 1.20 METER Superseded by part number: 3023376 |
| 101. | 73177721 | [1] | CONTAINER | BER Superseded by part number: 1414615, 1758400 |
| 104. | 73170203 | [2] | BOLT,Hex, M6 x 20, 8.8 | BERHEXAGON BOLT Superseded by part number: 120100 |
| 105. | 73170184 | [2] | NUT | BERHEXAGON NUT Superseded by part number: 84089790 |
| 106. | 73170185 | [4] | WASHER | BERDISK/WASHER Superseded by part number: 63707, 86625263 |
| 202. | 73177722 | [1] | CAP | BERSIEVE Superseded by part number: 1414615 |
