纽荷兰零件查询(EC130) - CRAWLER EXCAVATOR (4/99-) (19.502[001]) - TRACK BRAKE (S/N 11701-UP) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
824 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 73177078 | [1] | BRAKE | BER Superseded by part number: 2403336 |
| 2. | 73179472 | [1] | PISTON | BER Superseded by part number: 2426686 |
| 3. | 73177079 | [1] | HUB | BEREXTERNAL CASING Superseded by part number: 2426685 |
| 4. | 73177080 | [1] | COVER | BERCYLINDER/COVER Superseded by part number: 2426427 |
| 5. | 73177081 | [11] | DISC | BEREXTERNAL DISK Superseded by part number: 1445485 |
| 6. | 73177082 | [10] | DISC | BERINTERNAL DISK Superseded by part number: 1445484 |
| 8. | 73177083 | [14] | SPRING | BER Superseded by part number: 1465224 |
| 9. | 73177084 | [14] | SPRING | BER Superseded by part number: 1461414 |
| 10. | 73177085 | [1] | SNAP RING | BERCIRCLIP Superseded by part number: 370018 |
| 11. | 73177086 | [1] | SNAP RING | BER Superseded by part number: 2268999 |
| 12. | 73177087 | [1] | GASKET | BER Superseded by part number: 1439356 |
| 13. | 73177088 | [1] | GASKET | BER Superseded by part number: 1465226 |
