神钢零件查询(ED190LC-6E) - BLADE RUNNER EXCAVATOR/DOZER BTW YL03U0136 - YL03U0292 (1/05-12/06) (07-035) - CYLINDER, DOZER LIFT HYD (YY01VU0001F1) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
799 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY01VU0001F1 | [1] | LIFT CYLINDER,Double Acting, 57.15mm Rod, 209.55mm Stroke | KOBCYLINDER, LIFT DOZER |
| 1. | YY01VU0001S001 | [4] | RING | KOBRING, WIPER |
| 2. | YY01VU0001S002 | [1] | TUBE | KOBTUBE ASSY |
| 3. | YY01VU0001S005 | [1] | ROD | KOBROD ASSY |
| 4. | YY01VU0001S008 | [2] | BUSHING | KOBBUSHING |
| 5. | YY01VU0001S011 | [3] | FITTING | KOBFITTING, GREASE Superseded by part number: YY01VU0005S011 |
| 6. | YY01VU0001S013 | [1] | LOCK NUT | KOBLOCK NUT |
| 7. | YY01VU0001S012 | [1] | PISTON | KOBPISTON |
| 8. | YY01VU0001S014 | [1] | O-RING | SMO-RING |
| 9. | YY01VU0001S015 | [1] | BACK-UP RING | SMBACK-UP |
| 10. | YY01VU0001S016 | [1] | WIPER | SMWIPER |
| 11. | YY01VU0001S017 | [1] | O-RING | SMO-RING |
| 12. | YY01VU0001S004 | [1] | HEAD | KOBHEAD |
| 13. | YY01VU0001S018 | [1] | O-RING | SMO-RING |
| 14. | YY01VU0001S019 | [2] | WEAR RING | SMWEAR RING |
| 15. | YY01VU0001S020 | [1] | SEAL | SMSEAL |
| 16. | YY01VU0001S021 | [2] | WEAR RING | SMWEAR RING |
| 17. | YY01VU0001S022 | [1] | SEAL | SMSEAL |
| 18. | ZE72X08000 | [4] | PLUG | KOB1/2" PF, (Incls. O-Ring ZD12P01800) |
