凯斯零件查询(LB424R) - BALER (9/12-) (27.550.040) - HYDRAULIC BRAKES, SINGLE AXLE Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
316 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84568895
|
[1] |
AXLE
|
ZED
|
| 2. |
84568555
|
[2] |
PROTECTION PLATE
|
ZED
|
| 3. |
84568550
|
[4] |
BRAKE ASSY.
|
ZED
Superseded by part number: 84568869
|
| 4. |
84568349
|
[4] |
BRAKE SPRING
|
ZED
Superseded by part number: 84568869
|
| 5. |
84568552
|
[2] |
SPRING
|
ZED
Superseded by part number: 84568869
|
| 6. |
84519356
|
[16] |
STUD
|
ZED
, Serial Range: -C084 Superseded by part number: 84563598
|
| 6. |
47456247
|
[16] |
STUD
|
ZED
, Start Serial: D085
|
| 7. |
84568543
|
[2] |
DRUM
|
ZED
|
| 8. |
84100477
|
[2] |
RING
|
ZED
Superseded by part number: 84100478
|
| 9. |
84100478
|
[2] |
RING
|
ZED
|
| 10. |
84519319
|
[2] |
HUB
|
ZED
|
| 11. |
84041877
|
[2] |
SEALING RING
|
ZED
|
| 12. |
84568356
|
[4] |
SEAL
|
ZED
Superseded by part number: 84568870
|
| 13. |
84100479
|
[2] |
NUT
|
ZED
|
| 14. |
84212727
|
[2] |
COTTER PIN
|
ZED
|
| 15. |
14301931
|
[12] |
HEX SOC SCREW,M8 x 1.25 x 10mm, Cl 10.9, Full Thd
|
LEC
|
| 16. |
84100510
|
[2] |
COVER
|
ZED
|
| 17. |
84041879
|
[2] |
TAPERED BEARING
|
ZED
|
| 18. |
84041878
|
[2] |
TAPERED BEARING
|
ZED
Superseded by part number: 9832270
|
| 19. |
84568504
|
[4] |
COVER
|
ZED
|
| 20. |
84568539
|
[8] |
SPACER
|
ZED
|
| 21. |
84568561
|
[8] |
NUT
|
ZED
|
| 22. |
84568459
|
[4] |
CAP
|
ZED
|
| 23. |
84568557
|
[1] |
CAMSHAFT
|
ZED
RH
|
| 23. |
84568558
|
[1] |
CAMSHAFT
|
ZED
LH
|
| 24. |
84568553
|
[4] |
WASHER
|
ZED
Superseded by part number: 84568870
|
| 25. |
84568352
|
[2] |
BUSHING
|
ZED
Superseded by part number: 84568870
|
| 26. |
84100520
|
[2] |
CIRCLIP
|
ZED
Superseded by part number: 84568870
|
| 27. |
84568528
|
[2] |
RUBBER PAD
|
ZED
Superseded by part number: 84568870
|
| 28. |
84568568
|
[2] |
LUBE NIPPLE
|
ZED
|
| 29. |
84568363
|
[2] |
ADJUSTER
|
ZED
, Serial Range: -C084
|
| 29. |
84100527
|
[2] |
LEVER
|
ZED
, Start Serial: D085
|
| 30. |
84100529
|
[2] |
WASHER
|
ZED
|
| 31. |
84568347
|
[2] |
CIRCLIP,Ext
|
ZED
|
| 32. |
130004
|
[2] |
COTTER PIN,2.9mm OD x 31.4mm OAL
|
WIN
|
| 33. |
140069
|
[2] |
WASHER,M15 x 24 x 2 Thk
|
ZED
|
| 34. |
84053856
|
[1] |
LEVER
|
ZED
|
| 35. |
84045542
|
[1] |
PIN
|
ZED
|
| 36. |
84568354
|
[4] |
BUSHING
|
ZED
Superseded by part number: 84568869
|
| 37. |
84568350
|
[2] |
BRAKE SPRING
|
ZED
Superseded by part number: 84568869
|
| 38. |
84014244
|
[1] |
PIN
|
ZED
|
| 39. |
84014241
|
[2] |
SPRING
|
ZED
|
| 40. |
84212728
|
[1] |
PISTON
|
ZED
|
| 41. |
84208250
|
[1] |
AXLE
|
ZED
Incl 1 - 40, 42 - 45
|
| 42. |
47462799
|
[2] |
FIP KIT
|
ZED
Incl 6
|
| 43. |
84520485
|
[1] |
SEAL KIT
|
ZED
Incl 8, 9, 11
|
| 44. |
84568869
|
[2] |
KIT
|
ZED
Incl 3 - 5, 36, 37
|
| 45. |
84568870
|
[1] |
KIT
|
ZED
Incl 12, 24 - 28
|
