纽荷兰零件查询(EC130) - CRAWLER EXCAVATOR (4/99-) (10.101[001]) - HYD. OIL TANK MOUNTING PARTS (S/N 11701-12057) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
763 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NS | [1] | NOT SERVICED | BASHYD. OIL TANK SEE FIGURE 10.102/001 |
| 41. | 73177164 | [1] | INLET MANIFOLD | BERINTAKE MANIFOLD Superseded by part number: 1292611 |
| 42. | 73170160 | [4] | WASHER | BERDISK/WASHER Superseded by part number: 86625263 |
| 43. | 73171918 | [4] | SCREW,Hex Soc Hd, M8 x 30, 8.8 | BERCYL.HEAD SCREW Superseded by part number: 84089734 |
| 44. | 73177165 | [1] | O-RING | NH Superseded by part number: 73177166 |
