纽荷兰零件查询(EC130) - CRAWLER EXCAVATOR (4/99-) (10.200[001]) - FUEL TANK INSTALL.MATERIAL (S/N 11701-UP) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
249 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 73175539 | [3] | BALL JOINT HEAD | BERSOCKET Superseded by part number: 73188216 |
| 2. | 73170715 | [1] | WASHER | NHDISK/WASHER Superseded by part number: 84089872 |
| 3. | 73174391 | [3] | BOLT,Hex, M12 x 60, 8.8, Full Thd | BERHEXAGON BOLT Superseded by part number: 309086 |
| 4. | 73177163 | [1] | LOCK NUT,M12 x 1.75, Cl 8 | BERHEXAGON NUT Superseded by part number: 100038 |
| 5. | 73179458 | [1] | BRACKET | BER Superseded by part number: 1297050 |
