| 1. |
84357231
|
[1] |
SHIELD
|
ZED
|
| 1. |
84352861
|
[1] |
SHIELD
|
ZED
|
| 2. |
84355224
|
[1] |
SUPPORT
|
ZED
, Serial Range: -C098 Superseded by part number: 47617454
|
| 2. |
47617454
|
[1] |
SUPPORT
|
ZED
, Start Serial: D099
|
| 2. |
84355226
|
[1] |
SUPPORT
|
ZED
, Serial Range: -C098 Superseded by part number: 47617238
|
| 2. |
47617238
|
[1] |
SUPPORT
|
ZED
, Start Serial: D099
|
| 3. |
84598866
|
[1] |
PLATE
|
ZED
, Serial Range: -C055 Superseded by part number: 47617464
|
| 3. |
47419378
|
[1] |
PLATE
|
ZED
, Serial Range: -F056098 Superseded by part number: 47617464
|
| 3. |
47617464
|
[1] |
PLATE
|
ZED
, Start Serial: D099
|
| 3. |
47362584
|
[1] |
PLATE
|
ZED
, Serial Range: -C098 Superseded by part number: 47617299
|
| 3. |
47617299
|
[1] |
PLATE
|
ZED
, Start Serial: D099
|
| 4. |
84602342
|
[1] |
SHIELD
|
ZED
, Serial Range: -C055 Superseded by part number: 47417587
|
| 4. |
47417587
|
[1] |
SHIELD
|
ZED
, Start Serial: D056
|
| 4. |
84602341
|
[1] |
SHIELD
|
ZED
, Serial Range: -C055 Superseded by part number: 47417587
|
| 5. |
140046
|
[10] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 6. |
300389
|
[3] |
BOLT,M12 x 1.75 x 35mm, Cl 8.8
|
NH
Superseded by part number: 628-12035
|
| 7. |
86507486
|
[6] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 8. |
322358
|
[6] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 9. |
9706690
|
[6] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 10. |
300662
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 80mm, Cl 8.8
|
NH
|
| 11. |
395087
|
[1] |
INSULATOR BLOCK
|
ZED
|
| 12. |
47367719
|
[2] |
SHIELD
|
ZED
, Serial Range: -C136 Superseded by part number: 47825769
|
| 12. |
47825769
|
[2] |
SUPPORT
|
ZED
, Start Serial: D137
|
| 13. |
43140
|
[4] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8
|
NH
, Serial Range: -C136
|
| 13. |
328754
|
[4] |
CARRIAGE BOLT,M12 x 1.75 x 40mm, Cl 8.8
|
NH
, Start Serial: D137
|
| 15. |
9706685
|
[7] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 16. |
291186
|
[1] |
PROTECTION STRIP,9.9mm W
|
NH
L= 0.1 M Superseded by part number: 47560081, 47560080
|
| 17. |
120041
|
[2] |
CARRIAGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 18. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 19. |
100016
|
[2] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 20. |
84820086
|
[2] |
SILENTBLOC
|
PLO
, Serial Range: -C136
|
| 20. |
47800760
|
[2] |
RUBBER BUMPER
|
ZED
, Start Serial: D137
|
