| . . | YM32TU1039F4 | [1] | KIT, FIELD INSTAL | |
| 9. | 2420R349D085 | [1] | HOSE,6.35mm ID x 850mm L | KOB850mm Long (33-29/64 in) N/A - SUBSTITUTION |
| 20. | 2444R1120D110 | [1] | HOSE | KOB(1/4" PF) 1100mm Long (43-19/64 in) |
| 22. | 2444T2657D1 | [2] | HYD CONNECTOR | KOBM30x1.5mm - 3/4"-16UNF x 46mm Long |
| 23. | 2444T2958 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01800) |
| 24. | 2444Z2360 | [1] | TEE | KOB(2) 1/2" PF x 3/8" PF x 64mm Long (Incls. O-Ring ZD12P01400) |
| 26. | 2444Z2894 | [1] | 90 ELBOW | KOBElbow, 90° -- 1/4" PF (Incls. O-Ring ZD12P01100) |
| 29. | EN24S00008P1 | [2] | RELAY | KOB(5 Spade Relay) |
| 35. | HH25R04004G5 | [1] | HYD CONNECTOR | KOB(Incls. O-Ring ZD12P01100) |
| 37. | HX31E04330DX | [1] | HOSE | KOBHOSE |
| 38. | HX31E04365DX | [1] | HOSE | |
| 42. | LC35V00004F2 | [1] | SOLENOID VALVE | KOBASSY |
| 44. | LE03H01234P1 | [1] | CLAMP | KOB |
| 45. | LF03M01004P1 | [2] | BOOT | KOBBOOT |
| 47. | PY01P01043D3 | [6] | CABLE TIE,188mm L | KOBWire Ties -- 188mm Long |
| 50. | YB03M01003F2 | [1] | GRIP | KOBAssembly |
| 51. | YB03M01003F3 | [1] | GRIP | KOBAssembly |
| 57. | YM03HU1014P1 | [1] | TUBE | |
| 58. | YM03HU1015P1 | [1] | TUBE | |
| 59. | YM03HU1018P1 | [1] | BRACKET | |
| 60. | YM03HU1019P1 | [1] | BRACKET | |
| 63. | YM30VU1003P1 | [2] | BOLT | KOBRod, Threaded -- M08x1.25x268mm |
| 64. | YM30VU1004P1 | [1] | BOLT | KOBRod, Threaded -- M10x1.50x268mm |
| 82. | YN03M01483P1 | [2] | BOOT | KOBBOOT |
| 83. | YN11E01111P1 | [1] | HARNESS | KOBHARNESS |
| 85. | YN11E01113D1 | [1] | HARNESS | KOBHARNESS |
| 92. | YN68H01035P1 | [2] | CLAMP | KOBCLAMP |
| 93. | YN68H01071P1 | [1] | SUPPORT | KOBSUPPORT |
| 94. | YN68H01073P1 | [1] | BRACKET | KOBBRACKET |
| 96. | YT22V00006F4 | [4] | VALVE | KOBVALVE ASSY, REL |
| 101. | YY30V00051F1 | [2] | MANIFOLD | KOBCONTROL VALVE A |
| 103. | ZA24F22008 | [1] | HYD CONNECTOR | KOB1/2" PF - M30x1.50x84mm Long |
| 104. | ZA33F22008 | [1] | 90 ELBOW,M30 x 1.5 ORB x 1/2" NPT | KOB90° -- 1/2" PF - M30x1.50x34mm Long (Incls. O-Ring ZD12P02400) |
| 109. | ZD12P01800 | [4] | O-RING | KOBID 17.8mm x OD 20.2mm |
| 111. | ZE72X04000 | [2] | PLUG | KOB(PF 1/4) (Incls. O-Ring ZD12P01100) |
| 112. | ZE72X08000 | [2] | PLUG | KOB1/2" PF, (Incls. O-Ring ZD12P01800) |
| 113. | ZE72X16000 | [1] | PLUG | KOB(Incls. O-Ring ZD12P02900) |
| 116. | ZH22X04000 | [4] | HYD CONNECTOR,1/4" NPT x 1/4" NPT | KOB1/4"PFx36mm Long (Incls. O-Ring ZD12P01100) |
| 118. | ZH32X04000 | [2] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 90° -- PF 1/4, (Incls. O-Ring 237-6004) |
| 119. | ZH32X04006 | [1] | 90 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 3/8", O-Ring | KOB90° -- 1/4"x3/8"PF (Incls. O-Ring 237-6006 Alternate ZD12P01400) |
| 120. | ZH42X04000 | [1] | 45 ELBOW,Male, 30 Degree Fl, PF 1/4" x PF 1/4", O-Ring | KOBElbow, 45° -- (Incls. O-Ring 237-6004) |
| 121. | ZM61C06016 | [2] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| 123. | ZN18C10008 | [1] | NUT | KOBM10x1.50mm |
| 127. | ZS18C08065 | [4] | SCREW,Hex, M8 x 65mm | KOBM08x1.25x65mm |
| 129. | ZS18C10020 | [4] | SCREW,Hex, M10 x 20mm | KOBM10x1.50x20mm |
| 132. | ZS18C10060 | [1] | SCREW,Hex, M10 x 60mm | KOBM10x1.50x60mm |
| 133. | ZS18C12030 | [3] | SCREW,Hex, M12 x 30mm | KOBM12x1.75x30mm |
| 134. | ZS18C12040 | [2] | SCREW,Hex, M12 x 40mm | KOBM12x1.75x40mm |
| 140. | ZW16H10000 | [2] | WASHER | KOBID 11 x OD 24 x Th 3.2mm |
| 141. | ZW16H12000 | [5] | WASHER | KOBID 13 x OD 26 x Th 3.2mm |
| 142. | ZW16X08000 | [4] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 143. | ZW16X10000 | [4] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 148. | ZX21M08064 | [1] | HOSE | |
