纽荷兰零件查询(EC130) - CRAWLER EXCAVATOR (4/99-) (15.012[001]) - RADIATOR HYDRAULIC OIL (S/N 11701-UP) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
889 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 73179470 | [1] | OIL COOLER | BER Superseded by part number: 1296846 |
| 10. | 73178080 | [1] | OIL COOLER | BER Superseded by part number: 1481177 |
| 20. | 73178081 | [1] | SPARE PART | BERVENTILATION BOX Superseded by part number: 1481174 |
| 30. | 73178082 | [1] | GUARD | BERGRID Superseded by part number: 1481175 |
| 40. | 73178083 | [1] | FAN | BER Superseded by part number: 1481176 |
| 50. | NS | [1] | NOT SERVICED | BASGEAR MOTOR SEE FIGURE 22.130/001 |
| 60. | 73171058 | [10] | BOLT,Hex, M8 x 20, 8.8 | BERHEXAGON BOLT Superseded by part number: 120104 |
| 70. | 73179195 | [4] | BOLT | NHHEXAGON BOLT Superseded by part number: 73170520 |
| 80. | 73170161 | [4] | NUT,M8, Cl 8 | BERHEXAGON NUT Superseded by part number: 9706690 |
| 90. | 73170168 | [14] | LOCK WASHER | BER Superseded by part number: 57020 |
| 100. | 73170160 | [14] | WASHER | BERDISK/WASHER Superseded by part number: 86625263 |
| 110. | 73170170 | [4] | WASHER | BERDISK/WASHER Superseded by part number: 62543 |
