纽荷兰零件查询(EC130) - CRAWLER EXCAVATOR (4/99-) (20.260[001]) - OIL SUCTION SYSTEM (S/N 11701-UP) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
396 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 73177203 | [1] | INLET MANIFOLD | BERINTAKE MANIFOLD Superseded by part number: 1292620 |
| 2. | 73177204 | [1] | HOSE | BER Superseded by part number: 1292627 |
| 6. | 73170014 | [4] | BOLT,Hex, M16 x 40, 8.8 | BER Superseded by part number: 43168 |
| 7. | 73177165 | [1] | O-RING | NH Superseded by part number: 73177166 |
| 8. | 73170130 | [4] | WASHER | BERDISK/WASHER Superseded by part number: 934283R1 |
| 101. | 73177205 | [1] | FLEXIBLE HOSE | BERHOSE Superseded by part number: 1292629 |
| 102. | 73177206 | [2] | CLAMP | BER Superseded by part number: 2142028 |
