纽荷兰零件查询(EC130) - CRAWLER EXCAVATOR (4/99-) (20.610[003]) - HYDRAULIC SYSTEM SERVO CONTROL (S/N 12022-UP) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
843 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | NS | [2] | NOT SERVICED | BASFOOT REST PLATFORM SEE FIGURE 34.105/001 |
| 16. | 73171262 | [1] | CLIP | BER Superseded by part number: 1283442 |
| 60. | 73170392 | [1] | HYD CONNECTOR | BERSOCKET Superseded by part number: 1636028 |
| 61. | 73171264 | [2] | DIFFUSER | BERDISTRIBUTOR Superseded by part number: 1283445 |
| 62. | 73170255 | [2] | LUBE NIPPLE | BERNIPPLE Superseded by part number: 1148460 |
| 68. | 73171266 | [4] | PRESSURE SWITCH | BERPRESSUR.SWITCH Superseded by part number: 2977519 |
| 104. | 73171267 | [1] | HOSE | BER Superseded by part number: 1290991 |
| 115. | 73171268 | [1] | HOSE | BER Superseded by part number: 1283389 |
| 117. | 73171269 | [1] | HOSE | BER Superseded by part number: 1283391 |
| 119. | 73171270 | [1] | HOSE | BER Superseded by part number: 1283392 |
| 120. | 73171271 | [1] | HOSE | BER Superseded by part number: 1283393 |
| 121. | 73171272 | [1] | HOSE | BER Superseded by part number: 1283394 |
| 124. | 73175233 | [1] | HOSE | BER Superseded by part number: 1283387 |
