纽荷兰零件查询(EC130) - CRAWLER EXCAVATOR (4/99-) (20.641[002]) - HYDRAULIC SYSTEM CASCADE MOUNTING PARTS (S/N 11701-UP) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
783 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | NS | [1] | NOT SERVICED | BASHYDRAULIC SYSTEM CASCADE SEE FIGURE 20.642/002 |
| 105. | 73171805 | [1] | HOSE | BER Superseded by part number: 1284470 |
| 108. | 73171806 | [1] | HOSE | BER Superseded by part number: 1284468 |
| 111. | 73171298 | [1] | HOSE | BER Superseded by part number: 1283471 |
| 128. | 73171297 | [1] | HOSE | BER Superseded by part number: 1284469 |
| 203. | 73177733 | [1] | HOSE | BER Superseded by part number: 1295724 |
| 211. | 73175607 | [1] | HOSE | BER Superseded by part number: 1258321 |
| 212. | 73171810 | [1] | HOSE | NH Superseded by part number: 73171811 |
| 214. | 73175606 | [1] | HOSE | NH Superseded by part number: 73171786 |
| 215. | 73177734 | [1] | HOSE | BER Superseded by part number: 1295721 |
| 216. | 73177735 | [1] | HOSE | BER Superseded by part number: 1295549 |
| 218. | 73171816 | [1] | HOSE | NH Superseded by part number: 73171811 |
| 220. | 73171811 | [1] | HOSE | BER Superseded by part number: 1258323 |
| 223. | 73177737 | [1] | HOSE | BER Superseded by part number: 1258779 |
| 224. | 73177738 | [1] | HOSE | BER Superseded by part number: 1295729 |
| 225. | 73179492 | [1] | HOSE | BER Superseded by part number: 3001444 |
| 230. | 73175614 | [1] | HOSE | BER Superseded by part number: 1258859 |
| 241. | 73177740 | [1] | HOSE | BER Superseded by part number: 1268106 |
| 242. | 73177741 | [1] | HOSE | BER Superseded by part number: 1258318 |
| 253. | 73171813 | [1] | HOSE | BER Superseded by part number: 1258493 |
| 254. | 73171792 | [1] | HOSE | NH Superseded by part number: 73171793 |
