纽荷兰零件查询(EC130) - CRAWLER EXCAVATOR (4/99-) (20.642[002]) - HYDRAULIC SYSTEM CASCADE (S/N 11701-UP) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
281 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 73171275 | [1] | BRACKET | BER Superseded by part number: 1253419 |
| 2. | 73171276 | [6] | HYDRAULIC VALVE | BERVALVE Superseded by part number: 1725525 |
| 3. | 73171277 | [6] | HYDRAULIC VALVE | BERVALVE Superseded by part number: 1725526 |
| 4. | 73171278 | [11] | SOCKET | BERTUBE FITTING Superseded by part number: 1254370 |
| 5. | 73171279 | [1] | FITTING | BERSCREWING Superseded by part number: 2142470 |
| 8. | 73170392 | [3] | HYD CONNECTOR | BERSOCKET Superseded by part number: 1636028 |
| 9. | 73171281 | [1] | SOCKET | BER Superseded by part number: 1238104 |
| 10. | 73171282 | [1] | HYD CONNECTOR | BERPIPE SOCKET Superseded by part number: 1268127 |
| 12. | 73171283 | [1] | TUBE,12 mm OD, 59 mm Length | BERLINE Superseded by part number: 1256073 |
| 13. | 73171284 | [2] | DISTRIBUTOR | BER Superseded by part number: 2186962 |
| 14. | 73171285 | [1] | DISTRIBUTOR | BER Superseded by part number: 2247718 |
| 15. | 73171286 | [1] | DISTRIBUTOR | BER Superseded by part number: 2247716 |
| 16. | 73171287 | [1] | HYD CONNECTOR | BERPIPE SOCKET Superseded by part number: 2247719 |
| 17. | 73171288 | [1] | SOCKET | BER Superseded by part number: 2247717 |
| 18. | 73171266 | [1] | PRESSURE SWITCH | BERPRESSUR.SWITCH Superseded by part number: 2977519 |
| 20. | 73171289 | [1] | HYD CONNECTOR | BERTUBE FITTING Superseded by part number: 310324 |
| 23. | 73171265 | [1] | PRESSURE SWITCH | BERPRESSUR.SWITCH Superseded by part number: 1287056 |
| 25. | NS | [1] | NOT SERVICED | BASCONTROL VALVE SEE FIGURE 23.182/001 |
| 26. | 73170296 | [3] | HYD CONNECTOR | BERSOCKET Superseded by part number: 73170297 |
| 27. | 73171290 | [1] | ADAPTER | BERSOCKET/ADAPTER Superseded by part number: 1665706 |
| 136. | 73171291 | [1] | HOSE | BER Superseded by part number: 1264258 |
| 137. | 73171292 | [1] | HOSE | BER Superseded by part number: 1283472 |
| 201. | 73171293 | [2] | SEALING RING | BERROUND SEALING RING |
