凯斯零件查询(LB424R) - BALER (9/12-) (35.570.030) - STANDARD BALE EJECTION MECHANSIM, CYLINDER Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
284 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84571826
|
[1] |
SHAFT,25mm OD x 137mm L
|
ZED
|
| 2. |
84571834
|
[1] |
SHAFT,25mm OD x 79mm L
|
ZED
|
| 3. |
84470269
|
[1] |
HYDRAULIC CYLINDER,Double Acting, 45mm Rod, 470mm Stroke
|
ZED
Incl 7, Serial Range: -C098
|
| 3. |
47466446
|
[1] |
HYDRAULIC CYLINDER
|
ZED
Incl 7, Start Serial: D099
|
| 4. |
84571865
|
[2] |
SPACER,25mm ID x 35mm OD x 16mm L
|
ZED
|
| 5. |
84571856
|
[2] |
PLATE
|
ZED
|
| 6. |
338949
|
[2] |
CARRIAGE BOLT,M10 x 1.5 x 25mm, Cl 8.8
|
NH
|
| 7. |
84154203
|
[1] |
SEAL KIT
|
ZED
|
| 8. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 9. |
100016
|
[2] |
NUT,M10 x 1.5, Cl 8
|
NH
|
