纽荷兰零件查询(EC130) - CRAWLER EXCAVATOR (4/99-) (22.120[001]) - AXIAL PISTON MOTOR ADJUSTABLE INSTALL.MATERIAL (S/N 11701-UP) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
757 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 73179496 | [1] | HYDRAULIC MOTOR | BERVAR.DISPL.MOTOR Superseded by part number: 2458937 |
| 9. | 73175960 | [1] | LOCKING RING | BERCIRCLIP Superseded by part number: 370012 |
| 10. | 73172363 | [1] | SEAL | BERROT.SHAFT LIP SEAL Superseded by part number: 87603551 |
| 11. | 73179497 | [1] | LOCK WASHER | BERDISK/WASHER Superseded by part number: 45075 |
| 12. | 73171819 | [1] | O-RING | BER Superseded by part number: 2978384 |
| 14. | 73176857 | [1] | O-RING | BER Superseded by part number: 73175813 |
| 25. | 73179498 | [1] | O-RING | BER Superseded by part number: 73175814 |
| 107. | 73176855 | [1] | PLUG | BERSCREW PLUG Superseded by part number: 219157A1 |
| 120. | 73179499 | [2] | SCREW | BERCYL.HEAD SCREW Superseded by part number: 73179500 |
| 121. | 73179501 | [2] | SCREW | BERCYL.HEAD SCREW Superseded by part number: 218462 |
| 122. | 73179502 | [4] | SCREW | BERCYL.HEAD SCREW Superseded by part number: 73179503 |
| 124. | 73175172 | [3] | PLUG | BERSCREW PLUG Superseded by part number: 73175173 |
| 125. | 73175174 | [4] | PLUG | BERSCREW PLUG Superseded by part number: 1637351 |
| 126. | 73176862 | [1] | O-RING | NH Superseded by part number: 73170754 |
| 127. | 73175176 | [1] | O-RING | BER Superseded by part number: 73175177 |
| 130. | 73175179 | [1] | PLUG | BERSCREW PLUG Superseded by part number: 1466223 |
| 149. | 73175170 | [1] | PRESSURE RELIEF VALVE | NHPRESS. REG. VALVE Superseded by part number: 73179370 |
| 150. | 73175171 | [2] | PRESSURE RELIEF VALVE | BERPRESS.REL.VALVE Superseded by part number: 1445908 |
| 211. | 73175822 | [2] | O-RING | BER Superseded by part number: 1475965 |
| 311. | 73176863 | [1] | O-RING | NH Superseded by part number: 73172459 |
| 405. | 73175182 | [1] | O-RING | BER Superseded by part number: 1403721 |
| 501. | 73175183 | [1] | GASKET KIT | BERGASKET SET, 1 Superseded by part number: 8602905 |
| 502. | 73175820 | [1] | CAP | NH Superseded by part number: 73175821 |
