纽荷兰零件查询(EC130) - CRAWLER EXCAVATOR (4/99-) (22.500[001]) - ROTOR INSTALL.MATERIAL (S/N 11701-UP) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
576 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NS | [1] | NOT SERVICED | BASROTOR MOUNTING PARTS SEE FIGURE 22.501/001 |
| 3. | 73177251 | [1] | PLATE | BER Superseded by part number: 1263756 |
| 4. | 73170814 | [4] | BOLT,Hex, M16 x 45, 8.8 | BER Superseded by part number: 385922 |
| 5. | 73170130 | [4] | WASHER | BERDISK/WASHER Superseded by part number: 934283R1 |
| 8. | 73170183 | [4] | BOLT,Hex, M12 x 35, 8.8, Full Thd | BERHEXAGON BOLT Superseded by part number: 628-12035 |
| 9. | 73170169 | [4] | WASHER | BERDISK/WASHER Superseded by part number: 84089818 |
