纽荷兰零件查询(EC130) - CRAWLER EXCAVATOR (4/99-) (23.181[001]) - CONTROL VALVE MOUNTING PARTS (S/N 11701-UP) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
118 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NS | [1] | NOT SERVICED | BASCONTROL VALVE SEE FIGURE 23.182/002 |
| 2. | 73171874 | [1] | TUBE | BERLINE Superseded by part number: 1255766 |
| 3. | 73179506 | [1] | SENSOR | BERPRESSURE SENSOR Superseded by part number: 8912731 |
| 4. | 73171875 | [1] | SOCKET | BER Superseded by part number: 2268429 |
| 5. | 73171876 | [2] | SOCKET | BER/ADAPTER Superseded by part number: 1307803 |
| 6. | 73170296 | [1] | HYD CONNECTOR | BERSOCKET Superseded by part number: 73170297 |
| 10. | 73171877 | [1] | 3 WAY CONNECTION | BERSHUTTLE VALVE Superseded by part number: 1725679 |
| 11. | 73171878 | [1] | HOSE | BER Superseded by part number: 1276314 |
