凯斯零件查询(LB424R) - BALER (9/12-) (55.421.010) - CROP INDICATOR SENSOR - C136 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
965 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84386749
|
[1] |
WIRE HARNESS
|
ZED
|
| 2. |
84353558
|
[1] |
SENSOR
|
ZED
B023 - Sensor Left-Hand Side Crop
|
| 4. |
86050346
|
[5] |
CLAMP,9.5mm, Coat, 7.1mm Bolt Hole, P Type
|
WIN
|
| 5. |
445394
|
[8] |
RIVET,Pop, 3/16" x 1/2" OAL
|
ZED
Superseded by part number: 151-573
|
| 6. |
86566990
|
[18] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
|
| 7. |
84058832
|
[2] |
CLIP
|
ZED
|
| 8. |
675162
|
[2] |
WIRE CLAMP,6.3mm, Coat, 10.3mm Bolt Hole, P Type
|
NH
|
| 9. |
9512290
|
[2] |
RIVET,Pop, 4.8mm OD x 17.8mm L
|
ZED
|
