凯斯零件查询(LB424R) - BALER (9/12-) (55.629.010) - ELECTRONIC BALE LENGTH ADJUSTMENT Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
624 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84273462
|
[1] |
WIRE HARNESS
|
ZED
|
| 2. |
87544180
|
[1] |
MAGNET
|
ZED
|
| 3. |
87689087
|
[1] |
SENSOR
|
ZED
B019 - Sensor Bale Length System
|
| 4. |
86511042
|
[2] |
SCREW,Pan Head, M4 x 0.7 x 16mm, Cl 4.8
|
ZED
Superseded by part number: 13272214
|
| 5. |
86566990
|
[8] |
CABLE TIE,292mm OAL x 4.8mm W
|
ZED
CABLE STRAP
|
| 6. |
84144890
|
[8] |
CLIP
|
JES
|
| 7. |
84058832
|
[2] |
CLIP
|
ZED
|
| 8. |
9824840
|
[2] |
WASHER,4.3mm ID x 9mm OD x 0.8mm Thk
|
NH
Superseded by part number: 89824840
|
| 9. |
84372317
|
[1] |
WIPER MOTOR
|
ZED
|
| 10. |
445394
|
[2] |
RIVET,Pop, 3/16" x 1/2" OAL
|
ZED
Superseded by part number: 151-573
|
| 11. |
322357
|
[3] |
BELLEVILLE WASHER,M6 Bolt Size x 14mm OD x 1.3mm Thk
|
NH
|
| 12. |
86508568
|
[3] |
BOLT,Hex, M6 x 1 x 16mm, Cl 8.8
|
NH
|
| 13. |
86505868
|
[1] |
SERRATED NUT,Hex, M8 x 1.25, Cl 8
|
ZED
|
