凯斯零件查询(LB424R) - BALER (9/12-) (60.220.020) - PICK-UP, FRAME Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
379 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84280922
|
[1] |
FRAME
|
ZED
, Serial Range: -C136
|
| 1. |
47826642
|
[1] |
FRAME
|
ZED
, Start Serial: D137
|
| 1. |
84269065
|
[1] |
FRAME
|
ZED
, Serial Range: -C136
|
| 1. |
47824923
|
[1] |
FRAME
|
ZED
, Start Serial: D137
|
| 2. |
84224715
|
[1] |
PLATE
|
ZED
|
| 2. |
84215191
|
[1] |
PLATE
|
ZED
|
| 3. |
84218623
|
[4] |
ADJUSTING PLATE
|
ZED
|
| 4. |
84218700
|
[1] |
SHIELD
|
ZED
, Serial Range: -C149
|
| 4. |
47942051
|
[1] |
SHIELD
|
ZED
, Start Serial: D150
|
| 5. |
84242885
|
[1] |
SHIELD
|
ZED
, Serial Range: -C149
|
| 5. |
47942046
|
[1] |
SHIELD
|
ZED
, Start Serial: D150
|
| 5. |
84218702
|
[1] |
SHIELD
|
ZED
, Serial Range: -C149
|
| 5. |
47942058
|
[1] |
SHIELD
|
ZED
, Start Serial: D150
|
| 6. |
84274384
|
[27] |
BRACKET
|
ZED
|
| 7. |
86511478
|
[1] |
BOLT,Hex Serr, M8 x 1.25 x 16mm
|
ZED
|
| 8. |
120075
|
[3] |
BOLT,M10 x 1.5 x 106.58mm, Cl 8.8
|
NH
|
| 9. |
100037
|
[3] |
LOCK NUT,M10 x 1.5, Cl 8
|
NH
|
| 10. |
84218731
|
[1] |
PLATE
|
ZED
|
| 11. |
84218733
|
[1] |
PLATE
|
ZED
|
| 12. |
84280564
|
[1] |
SUPPORT
|
ZED
|
| 13. |
84268702
|
[1] |
SHIELD
|
ZED
, Serial Range: -C136
|
| 13. |
47812027
|
[1] |
SHIELD
|
ZED
, Start Serial: D137
|
| 14. |
84268704
|
[1] |
SHIELD
|
ZED
|
| 15. |
86507486
|
[4] |
CARRIAGE BOLT,M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 16. |
86624184
|
[2] |
WASHER,9mm ID x 16mm OD x 1.6mm Thk
|
FOR
|
| 17. |
336256
|
[2] |
NUT,M8, Cl 8
|
PA
Superseded by part number: 43362
|
| 18. |
120104
|
[1] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 19. |
43127
|
[2] |
BOLT,Hex, M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 20. |
43128
|
[1] |
BOLT,M8 x 1.25 x 30mm, Cl 8.8
|
NH
|
| 21. |
322358
|
[33] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 22. |
9706690
|
[7] |
NUT,M8 x 1.25, Cl 8
|
NH
Superseded by part number: 43362
|
| 23. |
120041
|
[18] |
CARRIAGE BOLT,M10 x 20mm, Cl 8.8
|
NH
|
| 24. |
140045
|
[18] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 25. |
100016
|
[18] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 26. |
86629542
|
[10] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
