纽荷兰零件查询(EC160) - CRAWLER EXCAVATOR (4/99-) (36.010[002]) - PANELING INSTALL.MATERIAL -A- (S/N 716039-716068) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
898 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 73187443 | [1] | PANEL | BERWALL Superseded by part number: 3008601 |
| 2. | 73179533 | [1] | SEAL | BERWALL Superseded by part number: 1297840 |
| 6. | 73179537 | [1] | COVER | BERCOVER Superseded by part number: 1297841 |
| 9. | 73182044 | [1] | PANEL | BERWALL Superseded by part number: 3007429 |
| 15. | 73182032 | [2] | BRACKET | BERBRACKET Superseded by part number: 3007425 |
| 23. | 73182045 | [1] | BRACKET | BERBRACKET Superseded by part number: 3007439 |
| 24. | 73179541 | [1] | BRACKET | BERBRACKET Superseded by part number: 1297842 |
| 25. | 73179542 | [2] | ANGLE | BERANGLE Superseded by part number: 1297843 |
| 26. | 73179543 | [1] | BAR | BERBAR Superseded by part number: 1297089 |
| 102. | 73187444 | [1] | FOAM INSULATION | BERINSULATION KIT Superseded by part number: 3008614 |
| 103. | 73170223 | [7] | CLIP | BERCLIP Superseded by part number: 6911927 |
| 104. | 73189574 | [1] | LID | BERLID Superseded by part number: 3024624 |
| 105. | 73170205 | [8] | BOLT,Hex, M8 x 16, 8.8 | BERHEXAGON BOLT Superseded by part number: 16043224 |
| 106. | 73170160 | [8] | WASHER | BERDISK/WASHER Superseded by part number: 86625263 |
