| 1. |
84216317
|
[1] |
CONE
|
ZED
|
| 2. |
84438926
|
[2] |
BALL BEARING,35mm ID x 72mm OD x 17mm W
|
NH
|
| 3. |
84216322
|
[1] |
SLEEVE
|
ZED
|
| 4. |
84429871
|
[1] |
WASHER
|
PLO
|
| 5. |
84566098
|
[1] |
SPROCKET
|
ZED
|
| 6. |
417723
|
[1] |
SEAL
|
ZED
Superseded by part number: 80417723
|
| 7. |
84567030
|
[1] |
AUGER
|
ZED
|
| 7. |
47590377
|
[1] |
AUGER
|
ZED
|
| 8. |
86633356
|
[5] |
CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8
|
ZED
|
| 9. |
675162
|
[2] |
WIRE CLAMP,6.3mm, Coat, 10.3mm Bolt Hole, P Type
|
NH
|
| 10. |
140045
|
[9] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 11. |
100016
|
[6] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 12. |
84274376
|
[1] |
SUPPORT
|
ZED
, Serial Range: -C136
|
| 12. |
47637506
|
[1] |
SUPPORT
|
ZED
, Start Serial: D137
|
| 13. |
120049
|
[1] |
CARRIAGE BOLT,Short Nk, M16 x 90mm, Cl 8.8
|
NH
|
| 14. |
84399198
|
[3] |
SLEEVE,17mm ID x 32mm OD x 5mm L
|
ZED
|
| 15. |
47407
|
[8] |
WASHER,16.7mm ID x 33.3mm OD x 0.75mm Thk
|
NH
|
| 16. |
84568878
|
[1] |
SPROCKET
|
ZED
, Serial Range: -C136 Superseded by part number: 47635044
|
| 16. |
47635046
|
[1] |
SPROCKET
|
ZED
, Start Serial: D137
|
| 17. |
370011
|
[1] |
CIRCLIP,M52 x 2mm Thk, Internal
|
ZED
Superseded by part number: 33915
|
| 18. |
443898
|
[1] |
BALL BEARING,25mm ID x 52mm OD x 15mm W
|
ZED
, Serial Range: -C136 Superseded by part number: 84188095
|
| 18. |
47462369
|
[1] |
BALL BEARING
|
COE
, Start Serial: D137
|
| 19. |
140048
|
[3] |
BELLEVILLE WASHER,M16 Bolt Size x 32mm OD x 2.8mm Thk
|
NH
|
| 20. |
100020
|
[3] |
NUT,M16 x 2.0, Cl 8
|
NH
|
| 21. |
1570477
|
[1] |
BOLT,Hex, M12 x 1.75 x 110mm, Cl 8.8, Full Thd
|
BER
Superseded by part number: 614-12110
|
| 22. |
140046
|
[3] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 23. |
9706685
|
[4] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 24. |
87517107
|
[2] |
DRIVEN SPROCKET
|
ZED
|
| 25. |
140020
|
[2] |
WASHER,17.5mm ID x 30mm OD x 3mm Thk
|
NH
|
| 26. |
120093
|
[2] |
BOLT,M16 x 2.0 x 90.18mm, Cl 8.8
|
NH
|
| 27. |
36403
|
[2] |
BEARING HOUSING
|
GI
Superseded by part number: 578189
|
| 28. |
43138
|
[3] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8
|
NH
|
| 29. |
84210631
|
[1] |
BEARING
|
ZED
|
| 30. |
140119
|
[2] |
WASHER,35.2mm ID x 42.5mm OD x 1.22mm Thk
|
ZED
|
| 31. |
84567996
|
[1] |
SPROCKET
|
ZED
|
| 32. |
9801096
|
[2] |
WASHER,13.5mm ID x 50.8mm OD x 4.76mm Thk
|
NH
|
| 33. |
300388
|
[2] |
BOLT,Hex, M12 x 1.75 x 25mm, Cl 8.8
|
NH
|
| 34. |
378245
|
[6] |
WASHER,13mm ID x 28.5mm OD x 2.7mm Thk
|
NH
|
| 35. |
84355794
|
[1] |
SLEEVE,12.5mm ID x 19mm OD x 9mm L
|
ZED
|
| 36. |
84355796
|
[1] |
SLEEVE,12.5mm ID x 19mm OD x 49.5mm L
|
ZED
|
| 37. |
87346700
|
[1] |
ARM
|
PA
|
| 38. |
84355805
|
[1] |
SUPPORT,M12
|
ZED
|
| 39. |
86508581
|
[1] |
BOLT,Hex, M12 x 90mm, Cl 8.8
|
NH
|
| 40. |
84355808
|
[1] |
SPRING
|
ZED
|
| 41. |
100038
|
[1] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 42. |
43128
|
[1] |
BOLT,M8 x 1.25 x 30mm, Cl 8.8
|
NH
|
| 43. |
322358
|
[1] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 44. |
84334697
|
[1] |
BUSHING,17mm ID x 32mm OD x 18.8mm L
|
ZED
, Serial Range: -C136
|
| 44. |
47637503
|
[1] |
HUB
|
ZED
, Start Serial: D137
|
| 45. |
86624184
|
[2] |
WASHER,9mm ID x 16mm OD x 1.6mm Thk
|
FOR
|
| 46. |
86629542
|
[1] |
NUT,M8 x 1.25, Cl 8.8
|
ZED
|
| 47. |
442293
|
[4] |
WASHER,36mm ID x 50mm OD x 1.5mm Thk
|
ZED
|
