神钢零件查询(K903B) - EXCAVATOR ASN LE3401 (1/85-12/03) (02-002) - INSTAL, CAB, (FOR EXPORT) P/N 24100J3166F21 Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
377 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J3166F21 | [1] | INSTAL , CAB, Serial Range: LE4162-LE5498 | |
| . . | 24100J3166F26 | [1] | INSTAL, CAB, Start Serial: LE5499 | |
| 3. | ZM11C10020 | [4] | SCREW | KOBM10x1.50x20mm (Incls. Lockwasher) Superseded by part number: ZM12C10020 |
| 8. | 2414R139 | [1] | FOAM INSULATION | KOB |
| 9. | 2414R137 | [1] | FOAM INSULATION | KOB |
| 10. | 2416T8662 | [1] | SHEET, RUBBER | SHEET, RUBBER |
| 13. | ZW13H16000 | [4] | WASHER | KOBID 17 x OD 32 x Th 4.5mm |
| 16. | ZW13H12000 | [2] | WASHER | KOB |
| 23. | 2416T6761D6 | [1] | SEAT,RUBBER | |
| 24. | 2414R162 | [1] | INSULATION,HEAT | |
| 25. | 2414R163 | [1] | INSULATION/HEAT, Serial Range: LE4162-LE4510 | |
| 26. | 2414R138D2 | [1] | INSULATION/ HEAT | |
| 28. | 2414R133 | [1] | INSULATION/ HEAT | |
| 31. | ZS18C16080 | [4] | SCREW,Hex, M16 x 80mm | KOBM16x2.0x80mm |
| 32. | ZS18C12025 | [2] | SCREW,Hex, M12 x 25mm | KOBM12x1.75x25mm |
| 40. | 24100U81F3 | [1] | SEAT ASSY | SEAT ASSY |
| 40-2. | 24100U81S2 | [1] | SUSPENSION | KOBSUSPENTION ASSY |
| 40-7. | 24100U81S7 | [1] | SEAT ASSY | SEAT ASSY |
| 43. | 24100J5084F1 | [1] | CAB ASSY,SEE FIG. 02-006, Serial Range: LE4162-LE4360 | |
| 50. | 2427U307D2 | [1] | MAT, FLOOR | |
| 57. | 24100J5084F3 | [1] | CAB ASSY, SEE FIG. 02-006, Serial Range: LE4361-LE4498 | |
| 63. | 24100J5084F5 | [1] | CAB ASSY SEE FIG. 02-006, Serial Range: LE4499-LE5498 | CAB ASSY SEE FIG. 02-006, Serial Range: LE4499-LE5498 |
| 66. | 2414R232D2 | [1] | FOAM INSULATION | KOB, Start Serial: LE4511 |
| 67. | ZS31C04006 | [2] | SCREW,Phillips Drive, Pan HD, M4 x 6mm | KOBM04x0.7x06mm, Start Serial: LE45U |
| 68. | 2418Z707 | [2] | WASHER, Start Serial: LE4511 | |
| 69. | 24100J5084F7 | [1] | CAB ASSY, SEE FIG. 02-006, Start Serial: LE5499 | |
