| . . | 24100J5084F2 | [1] | CAB ASSY, Serial Range: LE4162-LE4360 | |
| . . | 24100J5084F4 | [1] | CAB ASSY, (CAN BE REPLACED BY 24100J5084F2), Serial Range: LE4361-LE4498 | |
| . . | 24100J5084F6 | [1] | CAB ASSY, (CAN BE REPLACED BY 24100J5084F4), Serial Range: LE4499-LE5498 | |
| . . | 24100J5084F8 | [1] | CAB ASSY, Start Serial: LE5499 | |
| 1. | 2427J1273 | [1] | CAP, Serial Range: LE4162-LE4360 | |
| 2. | 24100J2500F1 | [1] | DOOR ASSY SEE FIG.02-011 | DOOR ASSY SEE FIG.02-011 |
| 3. | 2427J1272D2 | [1] | FRAME WINDOW, Serial Range: LE4162-LE4498 | |
| 4. | 24100P1031F1 | [1] | WINDOW | KOB |
| 4-1. | 24100P1031S1 | [1] | SASH | SASH |
| 4-2. | 24100P1031S2 | [1] | GUIDE | KOBSEAL |
| 4-3. | 24100P1031S3 | [4] | SPACER | SPACER |
| 4-4. | 2427R421 | [1] | GLASS | KOB |
| 4-5. | 2427R422 | [1] | GLASS | KOB |
| 4-6. | 24100P1031S4 | [1] | CHANNEL | KOB |
| 4-7. | 24100P1031S5 | [1] | SEAL | KOBDOOR |
| 4-8. | 24100P1031S6 | [2] | RETAINER | KOB |
| 4-9. | 24100P1031S7 | [2] | PACKING | PACKING |
| 4-10. | 24100P1031S8 | [2] | LOCK | KOB |
| 4-11. | 24100P1031S9 | [4] | SCREW | KOB |
| 4-12. | 2418T12332D2 | [8] | SPACER | KOB |
| 7. | 2427T784 | [1] | GLASS | KOB, Serial Range: LE4162-LE5498 |
| 8. | 2427Z527D2 | [1] | GLASS | GLASS |
| 11. | 2427T709 | [1] | GLASS | KOBGLASS, Serial Range: LE4162-LE4360 |
| 12. | 2417R65D7 | [1] | SEAL/ RUBBER | |
| 13. | 2417R65D5 | [1] | SEAL, RUBBER | SEAL, RUBBER |
| 14. | 2417R65D2 | [1] | RUBBER TRACK | KOBSEAL/ RUBBER Superseded by part number: R27T0006D1 |
| 15. | 2417R65D14 | [1] | RUBBER TRACK | KOBSEAL, RUBBER Superseded by part number: R27T0006D16 |
| 16. | 2417R65D8 | [1] | RUBBER TRACK | KOBSEAL, RUBBER Superseded by part number: R27T0006D16 |
| 17. | 2417R65D10 | [1] | RUBBER TRACK | KOBSEAL, RUBBER Superseded by part number: R27T0006D39 |
| 18. | 2427T526 | [1] | SEAT | KOB |
| 19. | 2416Z220D10 | [1] | SEAL | KOB |
| 20. | 2418R214D1 | [1] | PLATE | KOB |
| 21. | 2427P1391D1 | [1] | HANDRAIL | KOBGUARD |
| 22. | 2427P1391D2 | [1] | RAIL, HAND GUARD | RAIL, HAND GUARD |
| 23. | 2427P1391D3 | [1] | RAIL, HAND GUARD | RAIL, HAND GUARD |
| 24. | ZS31C06012 | [6] | SCREW,Phillips Drive, Pan HD, M6 x 12mm | KOBM06x1.0x12mm |
| 25. | 2429P560 | [1] | STFP | |
| 28. | 2420Z934 | [2] | STOP | KOB |
| 27. | ZN11C10008 | [2] | NUT | KOBM10x1.50mm Superseded by part number: ZN18C10008 |
| 28. | 2427P1644 | [1] | RAIL, HAND | RAIL, HAND |
| 29. | 2427P1417D2 | [1] | RAIL/ HAND | |
| 30. | 2416T6167 | [2] | RUBBER SLEEVE | KOBRUBBER |
| 31. | 24100X1045S148 | [8] | SCREW | KOB |
| 32. | 2427P1395 | [2] | LATCH | KOBHOOK |
| 33. | ZW11X06000 | [14] | WASHER | KOBID 06.6 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 35. | 2417R66D1 | [1] | RUBBER SEAL | KOB |
| 36. | 2417R66D2 | [1] | RUBBER SEAL | KOB |
| 37. | 2417Z257 | [2] | RUBBER SEAL | KOB, Serial Range: LE4162-LE4498 |
| 38. | 2412Z164 | [2] | STOP | KOB |
| 39. | 2416T7503 | [1] | BRACKET | KOB |
| 40. | 2416Z352 | [2] | U-BRACKET | KOB |
| 41. | 2421Z231D4 | [1] | BRUSH | BRUSH |
| 42. | 2421Z231D9 | [2] | BRUSH | BRUSH |
| 43. | 24100X1045S135 | [13] | BOLT | KOB |
| 44. | ZN11C08007 | [7] | NUT | KOBM08x1.25mm Superseded by part number: ZN16C08007 |
| 46. | 24100X1045S137 | [2] | SCREW | KOBBOLT, SET Superseded by part number: ZS18C08016 |
| 47. | 2418T10897 | [2] | SPACER | SPACER |
| 48. | 24100X1045S138 | [2] | MACHINESCREW, Serial Range: LF4162-LF4498 | MACHINESCREW, Serial Range: LF4162-LF4498 |
| 49. | 2416Z351 | [2] | CUSHION | KOB Superseded by part number: 192-9111-B-1 |
| 50. | 2418T6681 | [2] | PLATE | KOB, Serial Range: LE4162-LE4498 |
| 51. | ZN11F10008 | [2] | NUT | KOB Superseded by part number: ZN18F10008 |
| 52. | 24100X1045S139 | [16] | LOCK WASHER | KOBWASHER Superseded by part number: ZW26X05000 |
| 53. | 24100X1045S140 | [6] | BOLT | KOBBOLT, SET Superseded by part number: ZM12C08020 |
| 54. | 2427Z382 | [4] | ROLLER | KOB |
| 56. | ZR36X00800 | [5] | SNAP RING | KOBSNAP |
| 57. | 2416P7286 | [2] | BRACKET | KOB |
| 59. | ZW22X08300 | [12] | LOCK WASHER | |
| 60. | 2416T6170 | [2] | RUBBER | RUBBER |
| 61. | 2418T3991 | [2] | PLATE | KOB |
| 62. | 2406T894 | [1] | ROD | |
| 63. | ZX15K06010 | [1] | TUBE, NYLON | |
| 64. | 2406Z194 | [1] | GRIP | KOB |
| 65. | ZN16C05004 | [1] | NUT | KOBM05x0.8mm Superseded by part number: ZN18C05004 |
| 66. | 2416Z220D4 | [1] | SEAL | KOB |
| 67. | 2405T757 | [2] | BUSHING | BUSHING |
| 68. | ZW11X08000 | [10] | WASHER | KOBID 09 x OD 17 x Th 1.6mm Superseded by part number: ZW16X08000 |
| 69. | 24100X1045S144 | [4] | BOLT, SET SETSCREW | BOLT, SET SETSCREW |
| 70. | 24100X1045S145 | [16] | SCREW | KOBBOLT, SET CAPSCREW, SOCKET Superseded by part number: ZS23C05015 |
| 71. | 2418T6441 | [1] | PLATE | KOB |
| 72. | B16P0146 | [1] | BRACKET | BRACKET |
| 73. | B17P0004 | [1] | SPRING | KOB |
| 74. | ZW22X06000 | [11] | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm | LOCK WASHER ID 06 x OD 12.2 x Th 1.5mm |
| 75. | P19P0143054 | [1] | PIN | |
| 76. | 2418T6680 | [1] | PLATE | PLATE |
| 77. | 2418T6709 | [1] | PACKING | KOB |
| 78. | ZS16C08020 | [3] | SCREW | KOBCAPSCREW M08x1.25x20mm Superseded by part number: ZS18C08020 |
| 81. | 2420Z1008 | [24] | RIVET | KOB |
| 82. | 2408T302 | [1] | HOOK | |
| 84. | ZP15X02018 | [1] | SPLIT PIN | |
| 85. | 24100X1045S151 | [1] | SCREW | KOBSCREW Superseded by part number: ZS41C06020 |
| 86. | 24100X1045S143 | [2] | SCREW | KOBSCREW Superseded by part number: ZS41C06025 |
| 87. | 2427Z383 | [1] | STRIKER PLATE | KOB, Serial Range: LE4162-LE4498 |
| 89. | 2417S64D1 | [1] | SEAL, RUBBER | |
| 90. | 2422T547 | [2] | STEP | |
| 91. | ZM11C10025 | [4] | BOLT | KOBM10x1.50x25mm (Incls. Lockwasher) Superseded by part number: ZM12C10025 |
| 92. | 2432R219D2 | [1] | LATCH | KOB Superseded by part number: 24100P1062F1 |
| 93. | 2432R219D1 | [1] | LATCH | KOB, Serial Range: LE4162-LE4360 Superseded by part number: 24100P1062F2 |
| 94. | 2420T3422 | [10] | NUT, Serial Range: LE4162-LE4360 | NUT, Serial Range: LE4162-LE4360 |
| 95. | ZS31C05014 | [10] | SCREW,Phillips Drive, Pan HD, M5 x 14mm | KOBM05x0.8x14mm, Serial Range: LE4162-LE4360 |
| 96. | ZW26X05000 | [10] | LOCK WASHER | KOBLock -- ID 05 x OD 09 x Th 1.3mm, Serial Range: LE4162-LE4360 |
| 97. | 2418T6080 | [10] | PACKING | PACKING |
| 98. | 2427T514C2 | [1] | GLASS | GLASS |
| 99. | 2427T515C2 | [1] | GLASS | KOB |
| 100. | 2427T512C2 | [1] | GLASS | HIT |
| 101. | 2427T511C2 | [1] | GLASS | KOB |
| 102. | 2412T761 | [2] | STOPPER, Serial Range: LE4361-LE498 | STOPPER, Serial Range: LE4361-LE498 |
| 103. | ZS31C06010 | [4] | SCREW,Phillips Drive, Pan HD, M6 x 10mm | KOBM06x1.0x10mm, Serial Range: LE4361-LE4498 |
| 104. | 2427T844 | [1] | GLASS | KOB, Start Serial: LE436 |
| 105. | 2427J1279 | [1] | CAB, Serial Range: LE4361-LE4498 | |
| 106. | 2416R221D1 | [1] | CUSHION | KOB(L H), Start Serial: LE4499 |
| 107. | 2416R221D2 | [1] | CUSHION | KOB(R. H), Start Serial: LE4499 |
| 108. | ZS31C06020 | [2] | SCREW,Phillips Drive, Pan HD, M6 x 20mm | KOBM06x1.0x20mm, Start Serial: LE4499 |
| 109. | 2418T12195 | [2] | SPACER | KOB, Start Serial: LE4499 |
| 110. | 2417R67D2 | [1] | SEAL, RUBBER, Start Serial: LE4499 | SEAL, RUBBER, Start Serial: LE4499 |
| 111. | 2427J1285 | [1] | CAB, Start Serial: LE4499 | |
| 112. | 2427J1281D2 | [1] | FRAME, WINDOW, Serial Range: LE4499-LE5498 | |
| 113. | 2427Z548 | [1] | GLASS, Start Serial: LE5499 | |
| 114. | 2427J330D2 | [1] | FRAME, WINDOW, Start Serial: LE5499 | |
