凯斯零件查询(LB424R) - BALER (9/12-) (60.220.160) - PICK-UP, MAIN TRANSMISSION, RH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
488 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84391381
|
[1] |
PLATE
|
ZED
|
| 2. |
84350246
|
[1] |
SHAFT
|
ZED
|
| 3. |
100016
|
[1] |
NUT,M10 x 1.5, Cl 8
|
NH
|
| 4. |
86620027
|
[2] |
FLANGED BEARING,80.02mm ID x 147.6mm OD x 4mm Thk
|
NH
|
| 5. |
552945
|
[1] |
BEARING ASSY,40 mm ID x 80 mm OD x 30.2 mm
|
NH
Superseded by part number: 412441
|
| 6. |
374895
|
[12] |
CARRIAGE BOLT,M12 x 1.75 x 25mm, Cl 8.8
|
NH
|
| 7. |
140046
|
[15] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 8. |
9706685
|
[12] |
NUT,M12 x 1.75, Cl 8
|
NH
|
| 9. |
84272524
|
[1] |
SPROCKET
|
ZED
|
| 10. |
9801096
|
[1] |
WASHER,13.5mm ID x 50.8mm OD x 4.76mm Thk
|
NH
|
| 11. |
9706687
|
[1] |
BOLT,M12 x 1.75 x 30mm, Cl 8.8
|
NH
|
| 12. |
442203
|
[5] |
WASHER,41mm ID x 50mm OD x 0.91mm Thk
|
ZED
|
| 13. |
84274373
|
[1] |
CHAIN
|
ZED
Incl 19, Serial Range: -C098 Superseded by part number: 47662980
|
| 13. |
47662980
|
[1] |
CHAIN
|
ZED
Incl 19, Serial Range: -F099130
|
| 13. |
47794660
|
[1] |
CHAIN
|
ZED
Incl 19, Start Serial: D131
|
| 14. |
43260
|
[3] |
BOLT,Hex, M12 x 1.75 x 30mm, Cl 10.9, Full Thd
|
BHB
|
| 15. |
84348544
|
[1] |
PLATE
|
ZED
|
| 16. |
84348545
|
[1] |
SUPPORT
|
ZED
, Serial Range: -C149
|
| 16. |
47934522
|
[1] |
SUPPORT
|
ZED
, Start Serial: D150
|
| 17. |
86633356
|
[1] |
CARRIAGE BOLT,M10 x 34.8mm, Cl 8.8
|
ZED
|
| 18. |
140045
|
[1] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 19. |
165590
|
[1] |
CONNECTING LINK
|
PA
, Serial Range: -C130 Superseded by part number: 241-1316
|
| 19. |
47783767
|
[1] |
CONNECTING LINK
|
ZED
, Start Serial: D131
|
