| . . | 24100X1335F1 | [1] | CAB ASSY | |
| 1. | 2427X361 | [1] | CAB | |
| 2. | 2427J1269 | [1] | DOOR ASSY | DOOR ASSY |
| 3. | 2414T2024 | [1] | COVER | KOB |
| 4. | 2427P1814 | [1] | POCKET | |
| 5. | 2416Z218021 | [1] | SHEET, RUBBER | |
| 6. | 2414T2005 | [1] | BRACKET | |
| 7. | 2408P502 | [1] | HOOK | KOB |
| 9. | 2416P6185 | [1] | BRACKET | KOB |
| 9. | 2418T6441 | [1] | PLATE | KOB |
| 10. | B17P0004 | [1] | SPRING | KOB |
| 11. | 2414P2613 | [1] | COVER | KOB |
| 12. | ZP45X10045 | [1] | PIN | KOB |
| 13. | ZW16X10000 | [1] | WASHER | KOBID 10 x OD 21 x Th 2.0mm |
| 14. | ZP15K02018 | [1] | SPRING | KOBSPLIT Superseded by part number: ZP15K02035 |
| 15. | 2427T854 | [1] | ROD | KOB |
| 16. | 24100P1061F1 | [1] | WAD | KOB |
| 16-1. | 24100P1061S1 | [1] | FRAME | KOB |
| 16-2. | 2427T845 | [1] | GLASS | KOB |
| 16-3. | 2427T846 | [1] | GLASS | KOB |
| 16-4. | 24100P1061S2 | [1] | LOCK | KOBASSY |
| 16-5. | 24100P1061S3 | [1] | LOCK | KOBASSY |
| 16-6. | 24100P1061S4 | [1] | SEAL | KOB |
| 16-7. | 24100P1061S5 | [1] | GROMMET | KOBCANNEL |
| 16-8. | 24100P1061S6 | [1] | SEAL | KOBSTRIP, WEATHER |
| 16-9. | 24100P1061S7 | [1] | RUBBER | |
| 16-10. | 24100P1061S8 | [1] | RUBBER SLEEVE | KOB |
| 17. | 24100P12819F1 | [1] | SASH | |
| 17-1. | 24100N2819S1 | [1] | FRAME ASSY | FRAME ASSY |
| 17-2. | 2427T850 | [1] | GLASS | KOB |
| 17-3. | 2427T848 | [1] | GLASS | KOB |
| 17-4. | 2427T851 | [1] | GLASS | KOB |
| 17-5. | 24100N2819S2 | [1] | LOCK | LOCK |
| 17-6. | 24100N2819S3 | [1] | LOCK | LOCK |
| 17-7. | 24100N2819S4 | [1] | GUIDE | KOB |
| 17-8. | 24100N2819S5 | [1] | WEATHERSTRIP | KOB |
| 17-9. | 24100N2819S6 | [1] | SEAL | KOB |
| 17-10. | 24100N2819S7 | [1] | RUBBER | |
| 17-11. | 24100N2819S8 | [1] | RUBBER SLEEVE | KOB |
| 17-12. | 24100N2819S9 | [1] | RUBBER | |
| 18. | 2427T847 | [1] | GLASS | HIT |
| 19. | 2427T843 | [1] | GLASS | KOB |
| 20. | 2427T852 | [1] | GLASS | KOB |
| 21. | 2427T849 | [1] | GLASS | |
| 22. | 2427T855 | [1] | GLASS | HITGLASS |
| 23. | 2427T844 | [1] | GLASS | KOB |
| 24. | 2427T526 | [1] | SEAT | KOB |
| 25. | 2416Z342 | [1] | INSULATION, HEAT | |
| 26. | 2416R219 | [1] | INSULATION, HEAT | |
| 27. | 2416R220 | [1] | INSULATION, HEAT | |
| 28. | 2427P1910 | [1] | GUARD RAIL, HAND | GUARD RAIL, HAND |
| 30. | 24792760 | [1] | HARNESS | |
| 31. | 2406R220 | [1] | HANDLE | KOB |
| 31-2. | 2406R220S2 | [1] | KEY | KOB |
| 32. | 2427T853 | [1] | RAIL , HAND | |
| 33. | 2421Z285 | [1] | LH DOOR LOCK | KOB |
| 34. | 2406R221 | [1] | HANDLE | KOB |
| 35. | 2414T2006 | [1] | COVER | KOB |
| 36. | 2406R222 | [1] | HANDLE | |
| 37. | 2408T302 | [1] | HOOK | |
| 3S. | 2479Z761 | [1] | HARNESS | KOBHARNESS |
| 39. | 2479Z759D2 | [1] | HARNESS | |
| 40. | 2488Z155 | [2] | SPARE PART | HITMOTOR, WIPER Superseded by part number: 2456R173D20 |
| 41. | R79P0022D3 | [2] | WIPER ARM | KOBARM, WIPER |
| 42. | R79P0021 | [1] | WIPER BLADE | KOB, Serial Range: LE3401-LE5158 Superseded by part number: 2488Z8D3 |
| . . | 2479R718 | [1] | WIPER BLADE | KOB, Start Serial: LE5159 |
| 43. | 2456R117F2 | [1] | LIGHT | KOBROOM |
| 43-4. | 4056R4F1 | [1] | LAMP | KOBLIGHT ASST |
| 43-4G. | 4056Z19D1 | [1] | LIGHT | KOBLIGHT |
| 43-5. | 2456R117S5 | [1] | SWITCH | KOB |
| 43-6. | 2456R117S6 | [1] | BRACKET | |
| 43-7. | ZS41C04008 | [1] | CAPSCREW,M4 x 8mm | KOBSCREW M04x0.7x08mm |
| 44. | 2479Z894D1 | [1] | HARNESS | HARNESS |
| 45. | 2479Z894D2 | [1] | WIRE HARNESS | KOB |
| 46. | 2479Z893 | [1] | HARNESS | |
| 47. | P79PN021D2 | [1] | BLADE, WIPER | |
| 48. | 2406Z194 | [1] | GRIP | KOB |
| 49. | ZX15K06032 | [1] | TUBE, NYLON | |
| 50. | 2427Z510 | [2] | STOP | KOB |
| 51. | 2420Z990 | [3] | RIVET | |
| 52. | ZS31C03008 | [2] | SCREW,Phillips Drive, Pan HD, M3 x 8mm | KOBM03x0.5x08mm |
| 53. | 2416T10973 | [2] | BRACKET | |
| 54. | 2416Z220D8 | [1] | SOFT TRIM | KOBSPONGE |
| 55. | 2416Z343 | [1] | RUBBER | RUBBER |
| 56. | 2416Z341D4 | [1] | RUBBER | KOB |
| 57. | 2416Z341D2 | [1] | RUBBER | RUBBER |
| 58. | 2416Z341D3 | [1] | RUBBER | |
| 59. | 2416Z341D5 | [1] | RUBBER | RUBBER |
| 60. | 2416Z341D6 | [1] | RUBBER | |
| 61. | 2416Z341D1 | [1] | RUBBER | |
| 62. | ZS16C06016 | [4] | SCREW | KOBM06x1.0x16mm |
| 63. | 2416Z220D9 | [1] | TRIM, SPONGE TRIM/ SPONGE | TRIM, SPONGE TRIM/ SPONGE |
| 64. | ZN41C08000 | [2] | NUT | KOB |
| 65. | ZS18C08025 | [15] | SCREW,Hex, M8 x 25mm | KOBM08x1.25x25mm |
| 66. | ZW26X08000 | [17] | LOCK WASHER | KOBLock -- ID 08 x OD 15 x Th 2.0mm Superseded by part number: 83990583 |
| 67. | ZW16X08000 | [17] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 68. | ZS31C06020 | [28] | SCREW,Phillips Drive, Pan HD, M6 x 20mm | KOBM06x1.0x20mm |
| 69. | ZW26X06000 | [28] | LOCK WASHER | KOBID 06 x OD 07 x Th 1.5mm |
| 70. | ZW16X06000 | [28] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 71. | ZS31C05016 | [4] | BOLT,Phillips Drive, Pan HD, M5 x 16mm | KOBM05x0.8x16mm |
| 73. | ZS41C05014 | [2] | SCREW,M5 x 14mm | KOBM05x0.8x14mm |
| 74. | 2418T10698 | [12] | WASHER | |
| 75. | ZS31C04006 | [12] | SCREW,Phillips Drive, Pan HD, M4 x 6mm | KOBM04x0.7x06mm |
| 76. | ZN16F10008 | [2] | NUT | KOB Superseded by part number: ZN18F10008 |
| 77. | ZN16C05004 | [1] | NUT | KOBM05x0.8mm Superseded by part number: ZN18C05004 |
| 78. | ZP15K02012 | [1] | COTTER PIN | KOBSPLIT PIN Superseded by part number: ZP15K02035 |
| 79. | ZS18C08020 | [2] | SCREW,Hex, M8 x 20mm | KOBM08x1.25x20mm |
| 80. | 2427Z511 | [1] | ASH TRAY | KOBTRAY,ASH |
| 81. | ZS41C04003 | [2] | MACHINESCRFW | |
| 82. | 2414T2007 | [1] | COVER | KOBCOVER |
| 83. | 2432Z309D1 | [6] | CLAMP | KOB |
| 84. | 2479Z960 | [1] | HARNESS, Start Serial: LE5351 | |
| 85. | 2427T872 | [4] | STOPPER, Start Serial: LE5159 | |
| 86. | ZS31C06010 | [8] | SCREW,Phillips Drive, Pan HD, M6 x 10mm | KOBM06x1.0x10mm, Start Serial: LE5159 |
