凯斯零件查询(LB424R) - BALER (9/12-) (60.220.200) - PICK-UP, MAIN TRANSMISSION, CLUTCH Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
773 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
84226349
|
[1] |
CLUTCH
|
ZED
Incl 2 - 17
|
| 2. |
87565193
|
[8] |
BOLT AND NUT
|
BEL
Incl 3 - 4 Superseded by part number: 87012736
|
| 3. |
NSS
|
[8] |
NOT SOLD SEPARAT
|
CON
Bolt Incl in 2
|
| 5. |
84303481
|
[1] |
FLANGE
|
ZED
|
| 6. |
87565196
|
[4] |
DISC
|
BEL
|
| 7. |
87565197
|
[1] |
DRIVE PLATE,89mm ID x 142mm OD x 6mm Thk
|
BEL
|
| 8. |
87565198
|
[1] |
PLATE
|
BEL
|
| 9. |
87565204
|
[1] |
HUB
|
BEL
|
| 10. |
87388479
|
[1] |
LUBE NIPPLE
|
JES
|
| 11. |
87731721
|
[1] |
PLATE
|
ZED
Superseded by part number: 47362906
|
| 12. |
87565209
|
[3] |
REPAIR KIT
|
BEL
Incl 1 Pawl and 3 Springs
|
| 13. |
87565205
|
[1] |
PLATE
|
BEL
|
| 14. |
87565195
|
[1] |
SPACER
|
BEL
|
| 15. |
47598881
|
[1] |
BELLEVILLE SPRING
|
ZED
|
| 16. |
87565207
|
[1] |
RING
|
BEL
|
| 17. |
47598882
|
[1] |
HUB
|
ZED
|
